3-8(No.YA683<Rev.001>)
FUNCTION P.W. BOARD ASS'Y (FU-1ESA19688-2)
IR SENSOR P.W. BOARD ASS'Y (FU-1ESA19688-3)
JACK P.W. BOARD ASS'Y (FU-1ESA19688-4)
R904 FU-RCX4JATZ0123 C RESISTOR 12k
Ω
1/4W J
R906 FU-RRXAFR5H4701 MG RESISTOR 4.7k
Ω
1/10W F
R907 FU-RRXAFR5H4701 MG RESISTOR 4.7k
Ω
1/10W F
R908 FU-RRXAFR5H3901 MG RESISTOR 3.9k
Ω
1/10W F
R909 FU-RRXAFR5H3901 MG RESISTOR 3.9k
Ω
1/10W F
R910 FU-RRXAFR5H8200 MG RESISTOR 820
Ω
1/10W F
R911 FU-RRXAFR5H5601 MG RESISTOR 5.6k
Ω
1/10W F
R912 FU-RRXAFR5H2400 MG RESISTOR 240
Ω
1/10W F
R913 FU-RRXAFR5H2400 MG RESISTOR 240
Ω
1/10W F
R914 FU-RRXAFR5H2400 MG RESISTOR 240
Ω
1/10W F
R915 FU-RRXAFR5H2400 MG RESISTOR 240
Ω
1/10W F
R916 FU-RRXAJR5Z0181 MG RESISTOR 180
Ω
1/10W J
R917 FU-RCX4JATZ0271 C RESISTOR 270k
Ω
1/4W J
R918 FU-RCX4JATZ0682 C RESISTOR 6.8k
Ω
1/4W J
R919 FU-RN01471ZU001 O.M.F.RESISTOR 470
Ω
1W J
R920 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R921 FU-RRXAJR5Z0683 MG RESISTOR 68k
Ω
1/10W J
R922 FU-RN02120ZU001 O.M.F.RESISTOR 120
Ω
2W J
R923 FU-RCX4JATZ0102 C RESISTOR 1k
Ω
1/4W J
R925 FU-RRXAFR5H3301 MG RESISTOR 3.3k
Ω
1/10W F
R926 FU-RRXAFR5H9101 MG RESISTOR 9.1k
Ω
1/10W F
R928 FU-RCX4JATZ0272 C RESISTOR 2.7k
Ω
1/4W J
R929 FU-RCX4JATZ0101 C RESISTOR 100
Ω
1/4W J
R930 FU-RRXAFR5H3001 MG RESISTOR 3k
Ω
1/10W F
R931 FU-RRXAFR5H9101 MG RESISTOR 9.1k
Ω
1/10W F
R936 FU-RRXAJR5Z0151 MG RESISTOR 150
Ω
1/10W J
R937 FU-RRXAJR5Z0272 MG RESISTOR 2.7k
Ω
1/10W J
R938 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R939 FU-RN02R82ZU001 RESISTOR 0.82
Ω
2W J
R942 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R943 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R944 FU-RCX4JATZ0272 C RESISTOR 2.7k
Ω
1/4W J
R945 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R947 FU-RCX4JATZ0473 C RESISTOR 47k
Ω
1/4W J
R948 FU-RN02R82ZU001 RESISTOR 0.82
Ω
2W J
R949 FU-RCX4JATZ0182 C RESISTOR 1.8k
Ω
1/4W J
R950 FU-RCX4JATZ0271 C RESISTOR 270k
Ω
1/4W J
R953 FU-RN02390ZU001 RESISTOR 390
Ω
2W J
R954 FU-RN02120ZU001 O.M.F.RESISTOR 120
Ω
2W J
R955 FU-RN02390ZU001 RESISTOR 390
Ω
2W J
R959 FU-RRXAFR5H1202 MG RESISTOR 12k
Ω
1/10W F
R960 FU-RRXAFR5H6200 MG RESISTOR 620
Ω
1/10W F
R961 FU-RRXAFR5H3001 MG RESISTOR 3k
Ω
1/10W F
R962 FU-RCX4JATZ0271 C RESISTOR 270k
Ω
1/4W J
R963 FU-RRXAJR5Z0682 MG RESISTOR 6.8k
Ω
1/10W J
R964 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R965 FU-RCX4JATZ0273 C RESISTOR 27k
Ω
1/4W J
R966 FU-RCX4JATZ0332 C RESISTOR 3.3k
Ω
1/4W J
R967 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R968 FU-RCX4JATZ0272 C RESISTOR 2.7k
Ω
1/4W J
R969 FU-RRXAJR5Z0332 MG RESISTOR 3.3k
Ω
1/10W J
R970 FU-RRXAJR5Z0332 MG RESISTOR 3.3k
Ω
1/10W J
R971 FU-RRXAFR5H8201 MG RESISTOR 8.2k
Ω
1/10W F
R972 FU-RRXAFR5H5101 MG RESISTOR 5.1k
Ω
1/10W F
R973 FU-RCX4JATZ0271 C RESISTOR 270k
Ω
1/4W J
R974 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω
1/10W J
R975 FU-RCX4JATZ0271 C RESISTOR 270k
Ω
1/4W J
R976 FU-RRXAFR5H5601 MG RESISTOR 5.6k
Ω
1/10W F
R977 FU-RRXAJR5Z0272 MG RESISTOR 2.7k
Ω
1/10W J
R978 FU-RRXAJR5Z0822 MG RESISTOR 8.2k
Ω
1/10W J
R980 FU-RCX4JATZ0102 C RESISTOR 1k
Ω
1/4W J
R982 FU-RRXAFR5H5601 MG RESISTOR 5.6k
Ω
1/10W F
R983 FU-RRXAJR5Z0682 MG RESISTOR 6.8k
Ω
1/10W J
R985 FU-RCX4JATZ0272 C RESISTOR 2.7k
Ω
1/4W J
R986 FU-RRXAFR5H2400 MG RESISTOR 240
Ω
1/10W F
R987 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω
1/10W J
R994 FU-RRXAFR5H3301 MG RESISTOR 3.3k
Ω
1/10W F
R995 FU-RRXAFR5H0433 MG RESISTOR 43k
Ω
1/10W F
R997 FU-RN02R22ZU001 O.M.F.RESISTOR 0.22
Ω
2W J
L501 FU-LLARKBSTU100 INDUCTOR 10uH
L502 FU-LLARKBSTU100 INDUCTOR 10uH
L601 FU-LLEG0Z0XB008 LINE FILTER
L701 FU-LLAXJATTU2R2 INDUCTOR 2.2uH
L702 FU-LLAXJATTU2R2 INDUCTOR 2.2uH
L703 FU-LLAXJATTU2R2 INDUCTOR 2.2uH
L838 FU-LLAXJATTU2R2 INDUCTOR 2.2uH
L839 FU-LLAXJATTU2R2 INDUCTOR 2.2uH
L840 FU-LLAXJATTU2R2 INDUCTOR 2.2uH
T601 FU-LTT2PE0KT047 POWER TRANS
BC601 FU-LLBF00STU030 INDUCTOR
BC603 FU-LLBF00STU030 INDUCTOR
BC750 FU-LLBF00STU030 INDUCTOR
F601 FU-PBGZ20BAG021 FUSE 4A/250V
JK721 FU-JYEJ040YUQ03 S-JACK S-VIDEO IN
JK722 FU-JXRJ010YUQ05 PIN JACK VIDEO IN
JK723 FU-JXRJ010YUQ02 PIN JACK AUDIO(L) IN
JK724 FU-JYRJ010YUQ03 PIN JACK AUDIO(R) IN
Ref No. Part No. Part Name Description Local
JK725 FU-JXSJ020YUQ01 MINI JACK PC AUDIO IN
JK751 FU-JXGJ210LY001 21P CONNECTOR SCART
JK801 FU-JYSJ020LY002 HEADPHONE JACK HEADPHONE
SA601 FU-NVQZ10D471KB SURGE ABSORBER
Ref No. Part No. Part Name Description Local
D201 FU-QDTB0MTZJ5R6 ZENER DIODE
D202 FU-QDTB0MTZJ5R6 ZENER DIODE
D203 FU-QDTB0MTZJ5R6 ZENER DIODE
C201 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C202 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
R201 FU-RCX4GATZ0103 C RESISTOR 10k
Ω
1/4W G
R202 FU-RCX4JATZ0221 C RESISTOR 220
Ω
1/4W J
R203 FU-RCX4GATZ0152 C RESISTOR 1.5k
Ω
1/4W G
R204 FU-RCX4GATZ0152 C RESISTOR 1.5k
Ω
1/4W G
R205 FU-RCX4GATZ0222 C RESISTOR 2.2k
Ω
1/4W G
R206 FU-RCX4GATZ0272 C RESISTOR 2.7k
Ω
1/4W G
R207 FU-RCX4GATZ0472 C RESISTOR 4.7k
Ω
1/4W G
R208 FU-RCX4GATZ0682 C RESISTOR 6.8k
Ω
1/4W G
CN201 FU-WX1A8CN0-008 WIRE ASSEMBLY 6pin 250mm
CN202 FU-WX1A8CN0-002 WIRE ASSEMBLY 5pin
SW201 FU-SST0101AL038 TACT SWITCH MENU
SW202 FU-SST0101AL038 TACT SWITCH VOL -
SW203 FU-SST0101AL038 TACT SWITCH VOL +
SW204 FU-SST0101AL038 TACT SWITCH PROG -
SW205 FU-SST0101AL038 TACT SWITCH PROG +
SW206 FU-SST0101AL038 TACT SWITCH INPUT SELECT
SW207 FU-SST0101AL038 TACT SWITCH POWER
Ref No. Part No. Part Name Description Local
D301 FU-QDTB0MTZJ5R6 ZENER DIODE
D302 FU-NPWZ0LTL4234 LED POWER
D303 FU-NP4Z000L53HT LED STANDBY
C301 FU-CE1JMAVSL2R2 E CAPACITOR 2.2uF 50V M
R301 FU-RCX4JATZ0121 C RESISTOR 120
Ω
1/4W J
R302 FU-RRXAJR5Z0331 MG RESISTOR 330
Ω
1/10W J
R303 FU-RRXAJR5Z0331 MG RESISTOR 330
Ω
1/10W J
R304 FU-RRXAJR5Z0332 MG RESISTOR 3.3k
Ω
1/10W J
RS301 FU-USESJRSKK046 REMOTE SENSOR
Ref No. Part No. Part Name Description Local
C14 FU-CHD1JK30B562 C CAPACITOR 5600pF 50V K
C15 FU-CHD1JK30B562 C CAPACITOR 5600pF 50V K
R14 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω
1/10W J
R15 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω
1/10W J
R19 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω
1/4W J
R20 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω
1/4W J
R21 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R22 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω
1/10W J
R23 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω
1/10W J
R24 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω
1/10W J
JK11 FU-JXRJ010YUQ03 PIN JACK COMP Y IN
JK12 FU-JXRJ010YUQ04 PIN JACK COMP Pb IN
JK13 FU-JXRJ010YUQ01 PIN JACK COMP Pr IN
JK14 FU-JXRJ010YUQ02 PIN JACK COMP AUDIO(L) IN
JK15 FU-JYRJ010YUQ03 PIN JACK COMP AUDIO(R) IN
Ref No. Part No. Part Name Description Local
To Next Page
