JVC LT-19DA9BJ User Manual

(No.YA683<Rev.001>)3-9
INVERTER P.W. BOARD ASS'Y (FU-1ESA19502-1)
JUNCTION P.W. BOARD ASS'Y (FU-1ESA19502-2)
 Ref No. Part No. Part Name Description Local
Q401 FU-QQS002SA950F TRANSISTOR
Q402 FU-NQS4KTC3199P TRANSISTOR
Q403 FU-NQS4KTC3199P TRANSISTOR
Q404 FU-NQS1KTA1267P TRANSISTOR
Q405 FU-QQS02SC2120F TRANSISTOR
Q406 FU-QQWZ2SC4881F POW TRANSISTOR
 Q408 FU-QF2ZHAT2215R MOS FET
Q410 FU-NQS4KTC3199P TRANSISTOR
Q411 FU-NQS1KTA1267P TRANSISTOR
Q412 FU-NQS4KTC3199P TRANSISTOR
D402 FU-QDTZ001SS133 SI DIODE
D403 FU-QDTZ001SS133 SI DIODE
D405 FU-QDTB00MTZJ15 ZENER DIODE
D408 FU-QDTZ001SS133 SI DIODE
D409 FU-QDTZ001SS133 SI DIODE
D410 FU-QDTZ001SS133 SI DIODE
D411 FU-QDTZ001SS133 SI DIODE
D412 FU-QDTZ001SS133 SI DIODE
D413 FU-QDTZ001SS133 SI DIODE
D414 FU-QDTZ001SS133 SI DIODE
D415 FU-QDTZ001SS133 SI DIODE
D416 FU-QDTZ001SS133 SI DIODE
D418 FU-QDTZ001SS133 SI DIODE
D419 FU-QDTZ001SS133 SI DIODE
D422 FU-QDTZ001SS133 SI DIODE
D428 FU-QDTB0MTZJ5R6 ZENER DIODE
C401 FU-CHD1JK30B472 C CAPACITOR 4700pF 50V K
C402 FU-CA2A104DT018 CAPACITOR 0.1uF 100V J
C404 FU-CE1CMASDL221 E CAPACITOR 220uF 16V M
C405 FU-CA2A104DT018 CAPACITOR 0.1uF 100V J
C406 FU-CA3F5R0MR060 C CAPACITOR 5pF 3.15KV J
C407 FU-CHD1JK30B472 C CAPACITOR 4700pF 50V K
C408 FU-CA3F5R0MR060 C CAPACITOR 5pF 3.15KV J
C411 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C412 FU-CE1EMASDL470 E CAPACITOR 47uF 25V M
C413 FU-CE1EMZNDL102 E CAPACITOR 1000uF 25V M
C414 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K
C415 FU-CT2E114DT065 CAPACITOR 0.11uF 250V H
C416 FU-CCD3FJPSL120 C CAPACITOR 12pF 3KV J
C417 FU-CCD3FJPSL120 C CAPACITOR 12pF 3KV J
C418 FU-CA2K332MR054 C CAPACITOR 3300pF 630V K
C419 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K
C420 FU-CA2A104DT018 CAPACITOR 0.1uF 100V J
C450 FU-CHD1JK30B102 C CAPACITOR 1000pF 50V K
C451 FU-CHD1JK30B102 C CAPACITOR 1000pF 50V K
R401 FU-RRXAJR5Z0152 MG RESISTOR 1.5k
Ω 1/10W J
R402 FU-RCX4JATZ0273 C RESISTOR 27k
Ω 1/4W J
R404 FU-RRXAJR5Z0332 MG RESISTOR 3.3k
Ω 1/10W J
R405 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R406 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R407 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R408 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R409 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R412 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R413 FU-RCX4JATZ0122 C RESISTOR 1.2k
Ω 1/4W J
R414 FU-RRXAJR5Z0470 MG RESISTOR 470
Ω 1/10W J
R415 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R417 FU-RCX4JATZ0562 C RESISTOR 5.6k
Ω 1/4W J
R418 FU-RCX4JATZ0331 C RESISTOR 330
Ω 1/4W J
R419 FU-RRXAJR5Z0331 MG RESISTOR 330
Ω 1/10W J
R420 FU-RRXAJR5Z0822 MG RESISTOR 8.2k
Ω 1/10W J
R422 FU-RRXAJR5Z0824 MG RESISTOR 820k
Ω 1/10W J
R423 FU-RRXAJR5Z0223 MG RESISTOR 22k
Ω 1/10W J
R424 FU-RRXAJR5Z0912 MG RESISTOR 9.1k
Ω 1/10W J
R425 FU-RRXAJR5Z0560 MG RESISTOR 560
Ω 1/10W J
R426 FU-RRXAJR5Z0560 MG RESISTOR 560
Ω 1/10W J
R427 FU-RRXAJR5Z0564 MG RESISTOR 560k
Ω 1/10W J
R428 FU-RRXAJR5Z0564 MG RESISTOR 560k
Ω 1/10W J
R429 FU-RRXAJR5Z0824 MG RESISTOR 820k
Ω 1/10W J
R430 FU-RCX4JATZ03R3 C RESISTOR 3.3
Ω 1/4W J
R431 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω 1/10W J
R432 FU-RRXAJR5Z0821 MG RESISTOR 820
Ω 1/10W J
R435 FU-RRXAJR5Z0222 MG RESISTOR 2.2k
Ω 1/10W J
R437 FU-RCX4JATZ0472 C RESISTOR 4.7k
Ω 1/4W J
R438 FU-RRXAJR5Z0561 MG RESISTOR 560
Ω 1/10W J
R439 FU-RN02R68ZU001 O.M.F.RESISTOR 0.68
Ω 2W J
R440 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R441 FU-RRXAJR5Z0134 MG RESISTOR 130k
Ω 1/10W J
R442 FU-RRXAJR5Z0223 MG RESISTOR 22k
Ω 1/10W J
R454 FU-RN02R33ZU001 O.M.F.RESISTOR 0.33
Ω 2W J
R455 FU-RRXAJR5Z0223 MG RESISTOR 22k
Ω 1/10W J
R456 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
L403 FU-LLBD00PKV021 CHOKE COIL 22uH
L401B FU-LLC471KSF009 POWER INDUCTER
 T401 FU-LTZ3PC0MS003 TRANS
 Ref No. Part No. Part Name Description Local
CN403A FU-WX1A8CN0-101 WIRE ASSEMBLY 12pin
 Ref No. Part No. Part Name Description Local

JVC LT-19DA9BJ Specifications

General

Brand	JVC
Model	LT-19DA9BJ
Category	LCD TV
Language	English
