(No.YA683<Rev.001>)3-3
EXPLODED VIEW PARTS LIST
Ref.No. Part No. Part Name Description Local
1 FU-1EM023085 REAR CABINET
2 FU-1EM023353 FRONT CABINET
3 FU-UG190EB LCD PANEL UNIT
4 FU-1EM222223A DECORATION PLATE
5 FU-DSD0806XQ001 SPEAKER
6 FU-DSD0806XQ001 SPEAKER
7 FU-WAB0182K5002 POWER CORD LT-19DA1BJAK
7 FU-WAE0172LW006 POWER CORD LT-19DA1BUAK
10 FU-1EM427137 REAR COVER
11 FU-1EM323959 SENSOR LED LENS
12 FU-1EM426377 STAND RUBBER FOOT (x4)
13 FU-1EM022467 STAND COVER
16 FU-1EM325277 STAND NECK
22 FU-1EM222143A FUNCTION KNOB
25 FU-1EM323797 WALL MOUNT BRACKET (x4)
26 FU-1EM122473 SHIELD BOX
27 FU-1EM325219 SHIELD (T)
28 FU-1EM427320 FFC SHIELD
29 FU-1EM323940 STAND HINGE
30 FU-0EM404486 CLOTH
31 FU-1EM424258 CLOTH
32 FU-1EM425861 GASKET (x2)
33 FU-0EM400076 CLOTH(B) (x4)
35 FU-GBJS3060 SCREW M3x6(x25)
36 FU-0EM408146A DOUBLE SEMS SCREW M4x9(x2)
37 FU-1EM422042 HEX SCREW (x2)
38 FU-FPJ32100 DOUBLE SEMS SCREW M2x10(x2)
39 FU-GBJP3100 SCREW M3x10(x8)
40 FU-FPJ32060 DOUBLE SEMS SCREW M2x6(x2)
41 FU-GBHP3100 SCREW M3x10(x7)
42 FU-GBHP4180 SCREW M4x18(x2)
43 FU-GBHS3060 SCREW M3x6(x2)
44 FU-GBHS3040 SCREW M3x4(x2)
50 FU-WX1A8CN0-012 WIRE ASSEMBLY 7pin CL107
51 FU-WX1A8CN0-013 WIRE ASSEMBLY 2pin CL451
52 FU-WX1A8CN0-013 WIRE ASSEMBLY 2pin CL802
53 FU-WX1A8CN0-006 WIRE ASSEMBLY 25pin CL3601
54 FU-WX1A8CN0-006 WIRE ASSEMBLY 25pin CL3701
55 FU-WX1A8CN0-005 WIRE ASSEMBLY 23pin CL3704
56 FU-WX1A8A70-101 FFC WIRE 55pin CL4501
57 FU-WX1A8A70-101 FFC WIRE 55pin CL4502
58 FU-WX1A8CN0-006 WIRE ASSEMBLY 25pin CL4503
59 FU-J6Q568CTK002 IC CARD CONNECTOR
101 FU-1ESA19688-1 MAIN PWB Please note that the TUNER is not included in MAIN PWB LT-19DA1BJAK
101 FU-1ESA19148-1 MAIN PWB Please note that the TUNER is not included in MAIN PWB LT-19DA1BUAK
102 FU-1ESA19688-2 FUNCTION PWB LT-19DA1BJAK
102 FU-1ESA19148-2 FUNCTION PWB LT-19DA1BUAK
103 FU-1ESA19688-3 IR SENSOR PWB LT-19DA1BJAK
103 FU-1ESA19148-3 IR SENSOR PWB LT-19DA1BUAK
104 FU-1ESA19688-4 JACK PWB LT-19DA1BJAK
104 FU-1ESA19148-4 JACK PWB LT-19DA1BUAK
105 FU-1ESA19502-1 INVERTER PWB
106 FU-1ESA19502-2 JUNCTION PWB
107 FU-1ESA19709 DIGITAL MAIN PWB LT-19DA1BJAK
107 FU-1ESA19153 DIGITAL MAIN PWB LT-19DA1BUAK
TU1 FU-UTUNPSGAL013 TUNER UNIT TU501
