3-10(No.YA683<Rev.001>)
PRINTED WIRING BOARD PARTS LIST [LT-19DA1BU/AK]
MAIN P.W. BOARD ASS'Y (FU-1ESA19148-1)
 Ref No. Part No. Part Name Description Local
 IC601 FU-QPEL561L11AV PHOTO COUPLER
IC801 FU-QSZBA0SMS017 IC
IC802 FU-NSZBA0TTY192 IC AUDIO D/A
IC850 FU-QSZBA0TTS162 IC SWITCHING
IC851 FU-QSZBA0TTS163 IC SWITCH
IC900 FU-NSZBA0SJY041 IC REG 5V
IC902 FU-NSZBA0SJY062 IC REG
Q505 FU-NQS4KTC3199P TRANSISTOR
 Q600 FU-QFWZ02SK3566 FET
 Q601 FU-QQS02SC2120F TRANSISTOR
Q726 FU-NQS1KTA1267P TRANSISTOR
Q727 FU-NQS1KTA1267P TRANSISTOR
Q731 FU-NQS4KTC3199P TRANSISTOR
Q734 FU-NQS1KTA1267P TRANSISTOR
Q744 FU-NQS4KTC3199P TRANSISTOR
Q802 FU-NQS4KTC3199P TRANSISTOR
Q805 FU-NQS4KTC3199P TRANSISTOR
Q900 FU-NQS4KTC3199P TRANSISTOR
Q901 FU-QQS02SC2120F TRANSISTOR
Q902 FU-QQS02SC2120F TRANSISTOR
Q903 FU-NQS4KTC3199P TRANSISTOR
Q904 FU-NQS4KTC3199P TRANSISTOR
Q906 FU-QQS02SC2120F TRANSISTOR
Q907 FU-NQS1KTA1267P TRANSISTOR
Q908 FU-NQS4KTC3199P TRANSISTOR
Q911 FU-NQS1KTA1267P TRANSISTOR
Q912 FU-NQS4KTC3199P TRANSISTOR
Q920 FU-NQS4KTC3199P TRANSISTOR
Q922 FU-NQE0KTD2059P TRANSISTOR
Q936 FU-QQWZ2SC4881F POW TRANSISTOR
D501 FU-QDTZ001SS133 SI DIODE
 D610 FU-QDTB00MTZJ22 ZENER DIODE
 D611 FU-NDLZ001N5399 SI DIODE
D612 FU-QDTB0MTZJ5R6 ZENER DIODE
 D613 FU-NDLZ001N5399 SI DIODE
 D614 FU-NDLZ001N5399 SI DIODE
D615 FU-QDTZ001SS133 SI DIODE
 D616 FU-NDLZ001N5399 SI DIODE
D621 FU-QDTZ001SS133 SI DIODE
D622 FU-QDTZ001SS133 SI DIODE
D624 FU-QDLZ001ZC18Q ZENER DIODE
 D629 FU-QDTB00MTZJ33 ZENER DIODE
D701 FU-QDTB00MTZJ13 ZENER DIODE
D702 FU-QDTB00MTZJ13 ZENER DIODE
D755 FU-QDTB0MTZJ3R9 ZENER DIODE
D758 FU-QDTB00MTZJ13 ZENER DIODE
 D802 FU-QDTZ001SS133 SI DIODE
 D803 FU-QDTB0MTZJ4R7 ZENER DIODE
 D900 FU-NDQZ000SB360 SB DIODE
D901 FU-NDL1000FR104 FR DIODE
 D903 FU-NDL1000FR104 FR DIODE
 D904 FU-NDLZ000FR154 DIODE
 D905 FU-NDL1000FR104 FR DIODE
 D906 FU-NDQZ000SB340 SB DIODE
D908 FU-QDLZ001ZC43Q DIODE
D909 FU-NDQZ001N4005 SI DIODE
D910 FU-QDTZ001SS133 SI DIODE
D911 FU-QDTZ001SS133 SI DIODE
D912 FU-QDTZ001SS133 SI DIODE
 D913 FU-QDTB0MTZJ5R6 ZENER DIODE
D915 FU-QDTB00MTZJ33 ZENER DIODE
D916 FU-NSZBA0TJY036 IC REGULATOR
D918 FU-QDTB00MTZJ12 ZENER DIODE
D919 FU-QDTZ001SS133 SI DIODE
D920 FU-NSZBA0TJY036 IC REGULATOR
D922 FU-QDTZ001SS133 SI DIODE
D923 FU-QDTB00MTZJ24 ZENER DIODE
 D924 FU-NDWZ000SB270 SB DIODE
D925 FU-QDTZ001SS133 SI DIODE
D926 FU-QDTB00MTZJ10 ZENER DIODE
D927 FU-QDTZ001SS133 SI DIODE
D928 FU-QDTB0MTZJ6R8 ZENER DIODE
D929 FU-QDTZ001SS133 SI DIODE
D930 FU-QDTZ001SS133 SI DIODE
D931 FU-QDTZ001SS133 SI DIODE
D935 FU-QDTZ001SS133 SI DIODE
D936 FU-NSZBA0TJY036 IC REGULATOR
D942 FU-QDTZ001SS133 SI DIODE
D944 FU-QDTZ001SS133 SI DIODE
D947 FU-QDTZ001SS133 SI DIODE
D948 FU-QDTZ001SS133 SI DIODE
D951 FU-QDTB00MTZJ15 ZENER DIODE
D953 FU-QDTZ001SS133 SI DIODE
D954 FU-QDTZ001SS133 SI DIODE
D955 FU-QDTB00MTZJ39 ZENER DIODE
D956 FU-QDTZ001SS133 SI DIODE
D966 FU-QDTZ001SS133 SI DIODE
D967 FU-QDTZ001SS133 SI DIODE
D970 FU-QDTZ001SS133 SI DIODE
D973 FU-QDTZ001SS133 SI DIODE
D974 FU-NDQZ001N4005 SI DIODE
D975 FU-NDQZ001N4005 SI DIODE
D985 FU-NSZBA0TJY036 IC REGULATOR
D986 FU-QDTZ001SS133 SI DIODE
D987 FU-QDTZ001SS133 SI DIODE
D988 FU-QDTZ001SS133 SI DIODE
D989 FU-QDTZ001SS133 SI DIODE
 D990 FU-QDLZ030PHA20 SB DIODE
C102 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J
C103 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J
C104 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C105 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C508 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K
C510 FU-CE1AMASDL101 E CAPACITOR 100uF 10V M
C512 FU-CHD1JJ3CH470 C CAPACITOR 47pF 50V J
C516 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C517 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C518 FU-CE1AMASDL102 E CAPACITOR 1000uF 10V M
C519 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C520 FU-CHD1JJ3CH470 C CAPACITOR 47pF 50V J
C524 FU-CE1CMAVSL330 E CAPACITOR 33uF 16V M
C525 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C526 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
 C600 FU-CT2E224MS037 CAPACITOR 0.22uF 250V
 C601 FU-CT2E104DC017 CAPACITOR 0.1uF 250V
 C615 FU-CA2H181DYG10 E CAPACITOR 180uF 400V M
C621 FU-CA3D471PAN04 C CAPACITOR 470pF 2kV
C623 FU-CA2A103DT018 CAPACITOR 0.01uF 100V J
C624 FU-CA2A152DT018 CAPACITOR 0.0015uF 100V J
C625 FU-CA2A473DT018 CAPACITOR 0.047uF 100V J
 C642 FU-CA2E332MR101 CAPACITOR 3300pF 250V K
C702 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C703 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C707 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J
C710 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C711 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C712 FU-CHD1JK30B562 C CAPACITOR 5600pF 50V K
C714 FU-CHD1JK30B562 C CAPACITOR 5600pF 50V K
C716 FU-CHD1JK30B562 C CAPACITOR 5600pF 50V K
C718 FU-CHD1JK30B562 C CAPACITOR 5600pF 50V K
C720 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C721 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C722 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C723 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C731 FU-CHD1JK30B562 C CAPACITOR 5600pF 50V K
C732 FU-CHD1JK30B562 C CAPACITOR 5600pF 50V K
C733 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C734 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C741 FU-CHD1JK30B222 C CAPACITOR 2200pF 50V K
C742 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C744 FU-CHD1JK30B222 C CAPACITOR 2200pF 50V K
C745 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C747 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C751 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C753 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C756 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C758 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C788 FU-CE1CMASDL101 E CAPACITOR 100uF 16V M
C789 FU-CE0KMAVSL331 E CAPACITOR 330uF 6.3V M
C791 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C792 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C793 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C794 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C795 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C796 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C797 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C801 FU-CE1CMASDL471 E CAPACITOR 470uF 16V M
C802 FU-CE1CMASDL471 E CAPACITOR 470uF 16V M
C806 FU-CE1EMASDL470 E CAPACITOR 47uF 25V M
C808 FU-CE1AMASDL101 E CAPACITOR 100uF 10V M
C809 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C810 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C811 FU-CE1EMASDL470 E CAPACITOR 47uF 25V M
C812 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C816 FU-CE1JMASDL220 E CAPACITOR 22uF 50V M
C818 FU-CE1CMASDL471 E CAPACITOR 470uF 16V M
C819 FU-CHD1JK30B392 C CAPACITOR 3900pF 50V K
 Ref No. Part No. Part Name Description Local
