(No.YA683<Rev.001>)3-7
C820 FU-CHD1JK30B392 C CAPACITOR 3900pF 50V K
C822 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C823 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C824 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C825 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C826 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C827 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C835 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J
C836 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J
C837 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C883 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C884 FU-CHD1AK30B105 C CAPACITOR 1uF 10V K
C892 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J
C894 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J
C895 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C896 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C900 FU-CE1AMZNDL332 E CAPACITOR 3300uF 10V
C901 FU-CE1JMASDL2R2 E CAPACITOR 2.2uF 50V M
C902 FU-CE1EMZPDL222 E CAPACITOR 2200uF 25V M
C903 FU-CE1JMASDL101 E CAPACITOR 100uF 50V M
C904 FU-CE1EMASDL331 E CAPACITOR 330uF 25V M
C905 FU-CE1EMASDL470 E CAPACITOR 47uF 25V M
C907 FU-CE0KMASDL222 E CAPACITOR 2200uF 6.3V M
C909 FU-CA2A272DT018 CAPACITOR 0.0027uF 100V J
C910 FU-CE1JMASDL220 E CAPACITOR 22uF 50V M
C911 FU-CE1CMASDL471 E CAPACITOR 470uF 16V M
C912 FU-CE1JMASDL1R0 E CAPACITOR 1uF 50V M
C914 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C916 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C917 FU-CE1CMASDL102 E CAPACITOR 1000uF 16V M
C920 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C921 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C922 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C923 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C924 FU-CE1CMASDL471 E CAPACITOR 470uF 16V M
C925 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C926 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C927 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C940 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C941 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C951 FU-CE1CMASDL221 E CAPACITOR 220uF 16V M
C952 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M
C953 FU-CE1AMASDL331 E CAPACITOR 330uF 10V M
C958 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C999 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
R102 FU-RRXAJR5Z0100 MG RESISTOR 10
Ω 1/10W J
R103 FU-RRXAJR5Z0100 MG RESISTOR 10
Ω 1/10W J
R511 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω 1/10W J
R512 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω 1/10W J
R515 FU-RRXAJR5Z0102 MG RESISTOR 1k
Ω 1/10W J
R522 FU-RRXAJR5Z0221 MG RESISTOR 220
Ω 1/10W J
R525 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω 1/10W J
R526 FU-RRXAJR5Z0470 MG RESISTOR 470
Ω 1/10W J
 R600 FU-RXX2JZLZ0105 RESISTOR 1M Ω 1/2W J
 R610 FU-RW051R2PG001 UNF.WW RESISTOR 1.2 Ω 5W K
R620 FU-RCX4JATZ0824 C RESISTOR 820k
Ω 1/4W J
R621 FU-RCX4JATZ0824 C RESISTOR 820k
Ω 1/4W J
R622 FU-RCX4JATZ0824 C RESISTOR 820k
Ω 1/4W J
R623 FU-RCX4JATZ0824 C RESISTOR 820k
Ω 1/4W J
R624 FU-RCX4JATZ0394 C RESISTOR 390k
Ω 1/10W J
R632 FU-RCX4JATZ0391 C RESISTOR 390
Ω 1/4W J
R633 FU-RCX4JATZ0391 C RESISTOR 390
Ω 1/4W J
R634 FU-RCX4JATZ0331 C RESISTOR 330
Ω 1/4W J
R635 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω 1/4W J
 R636 FU-RN02R68ZU001 O.M.F.RESISTOR 0.68 Ω 2W J
R637 FU-RCX4JATZ0151 C RESISTOR 150
Ω 1/4W J
R638 FU-RCX4JATZ0562 C RESISTOR 5.6k
Ω 1/4W J
R639 FU-RCX4JATZ0271 C RESISTOR 270k
Ω 1/4W J
R701 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R702 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R704 FU-RCX4JATZ0471 C RESISTOR 470
Ω 1/4W J
R707 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R708 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω 1/10W J
R713 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R714 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R716 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω 1/10W J
R717 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω 1/4W J
R718 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω 1/10W J
R719 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω 1/10W J
R720 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω 1/4W J
R721 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω 1/10W J
R722 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω 1/4W J
R723 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω 1/4W J
R729 FU-RRXAJR5Z0102 MG RESISTOR 1k
Ω 1/10W J
R730 FU-RCX4JATZ0471 C RESISTOR 470
Ω 1/4W J
R732 FU-RRXAJR5Z0471 MG RESISTOR 470
Ω 1/10W J
R737 FU-RCX4JATZ0471 C RESISTOR 470
Ω 1/4W J
R738 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω 1/10W J
 Ref No. Part No. Part Name Description Local
R739 FU-RRXAJR5Z0473 MG RESISTOR 47k Ω 1/10W J
R740 FU-RRXAJR5Z0470 MG RESISTOR 470
Ω 1/10W J
R741 FU-RCX4JATZ0561 C RESISTOR 560
Ω 1/4W J
R746 FU-RCX4JATZ0561 C RESISTOR 560
Ω 1/4W J
R751 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R752 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R756 FU-RCX4JATZ0153 C RESISTOR 15k
Ω 1/4W J
R757 FU-RRXAJR5Z0512 MG RESISTOR 5.1k
Ω 1/10W J
R758 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R759 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R761 FU-RCX4JATZ0471 C RESISTOR 470
Ω 1/4W J
R762 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω 1/10W J
R763 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R764 FU-RCX4JATZ0750 C RESISTOR 75
Ω 1/4W J
R765 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R766 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R767 FU-RRXAJR5Z0122 MG RESISTOR 1.2k
Ω 1/10W J
R768 FU-RCX4JATZ0471 C RESISTOR 470
Ω 1/4W J
R770 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R771 FU-RCX4JATZ0101 C RESISTOR 100
Ω 1/4W J
R775 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R776 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R777 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω 1/10W J
R778 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω 1/10W J
R779 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω 1/10W J
R780 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω 1/10W J
R781 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω 1/4W J
R782 FU-RRXAJR5Z0102 MG RESISTOR 1k
Ω 1/10W J
R783 FU-RCX4JATZ0152 C RESISTOR 1.5k
Ω 1/4W J
R784 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R785 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R786 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R787 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω 1/10W J
R788 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω 1/10W J
R793 FU-RRXAJR5Z0393 MG RESISTOR 39k
Ω 1/10W J
R794 FU-RRXAJR5Z0102 MG RESISTOR 1k
Ω 1/10W J
R797 FU-RRXAJR5Z0102 MG RESISTOR 1k
Ω 1/10W J
R801 FU-RRXAJR5Z0563 MG RESISTOR 56k
Ω 1/10W J
R802 FU-RRXAJR5Z0273 MG RESISTOR 27k
Ω 1/10W J
 R807 FU-RN024R7ZU001 O.M.F.RESISTOR 4.7 Ω 2W J
R808 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R809 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R811 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω 1/10W J
 R812 FU-RRXAJR5Z0222 MG RESISTOR 2.2k Ω 1/10W J
R813 FU-RCX4JATZ0103 C RESISTOR 10k
Ω 1/4W J
R814 FU-RRXAJR5Z0392 MG RESISTOR 3.9k
Ω 1/10W J
R816 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R817 FU-RRXAJR5Z0392 MG RESISTOR 3.9k
Ω 1/10W J
R818 FU-RRXAJR5Z0223 MG RESISTOR 22k
Ω 1/10W J
R822 FU-RRXAJR5Z0223 MG RESISTOR 22k
Ω 1/10W J
R824 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R825 FU-RCX4JATZ0103 C RESISTOR 10k
Ω 1/4W J
R829 FU-RCX4JATZ0121 C RESISTOR 120
Ω 1/4W J
R830 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R831 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R832 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R833 FU-RRXAJR5Z0330 MG RESISTOR 33
Ω 1/10W J
R834 FU-RRXAJR5Z0330 MG RESISTOR 33
Ω 1/10W J
R835 FU-RRXAJR5Z0330 MG RESISTOR 33
Ω 1/10W J
R836 FU-RRXAJR5Z0330 MG RESISTOR 33
Ω 1/10W J
R837 FU-RCX4JATZ0181 C RESISTOR 180
Ω 1/4W J
R838 FU-RCX4JATZ0181 C RESISTOR 180
Ω 1/4W J
R839 FU-RRXAJR5Z0473 MG RESISTOR 47k
Ω 1/10W J
R840 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
R842 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R843 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R844 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R845 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R846 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R847 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R848 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R849 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R850 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R852 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R854 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R855 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R856 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R857 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R858 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R859 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R890 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R891 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R892 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R893 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R894 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R895 FU-RCX4JATZ0104 C RESISTOR 100k
Ω 1/4W J
R896 FU-RRXAJR5Z0273 MG RESISTOR 27k
Ω 1/10W J
R897 FU-RRXAJR5Z0273 MG RESISTOR 27k
Ω 1/10W J
R900 FU-RCX4JATZ03R3 C RESISTOR 3.3
Ω 1/4W J
 Ref No. Part No. Part Name Description Local
