ITEM
1
2
3
5
6
BUTTON NAME
PC(VGA)
PC AUDIO
AV IN
HDMI
USB
Connect to the VGA output on your Comuter.
Connect to the Audio output jack of your Computer.
Composite input.
4 RF IN
Connect antenna here to get TV signal.
7 COAXIAL
Coaxial Digital Audio ouput.
8 YPbPr IN
Component video input.
FUNCTION DESCRIPTION
Pleasa Note:
Some USB memory devices, such as external hard drives and some portable hard
drives, require their own power supply to operate See also the Technical Specifica-
tions section for compatible file types and storage limits.
Connect to the HDMI output jack of up to 2 external video sources
(eg Bluray player/ games console)
Note: HDMI 2 port supports ARC function.
Plug in your USB memory device(eg. USB stick) to play
compatible files stored in it.
8
HDMI
VIDEO RL
AV IN
PC(VGA) PC AUDIO
RF IN
1
2 3 4 5
COAXIAL
USB
5V 500mA
5
6
7
8
Y PrPb
YPbPr IN
HDMI2
(ARC)
