JVC RX-F10S Service Manual

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 LV10867-005A FRONT PANEL
2 LV43622-002A FOOT (x2)
3 LV34669-001A INDICATOR
4 LV34668-001A DISPLAY LENS
5 LV21636-004A LENS
6 LV34671-001A P.BUTTON(POWER)
7 LV34672-001A P.BUTTON(SET)
8 LV43381-003A FILTER
9 LV21697-001A LED HOLDER
10 QYSBSF2608ZA TAP SCREW M6 x #NEV(x6)
11 QYSBSF2608ZA TAP SCREW M6 x #NEV(x4)
12 LV30225-0M7A SPECER
13 QYSBSF2608ZA TAP SCREW M6 x #NEV(x4)
14 QYSBSG3006ZA TAP SCREW M0 x #NEV(x4)
15 QYSBSG3006ZA TAP SCREW M0 x #NEV(x3)
16 LV10868-004A CHASSIS BASE
17 LV30225-0F4A SPACER
18 LV30225-0T1A SPACER
19 LV43622-002A FOOT (x2)
20 LV34681-002A SUPPORT BRACKET
21 LV30225-0F4A SPACER
22 QYSBST3005E TAP SCREW M3 x 5mm
23 LV34679-001A PWB BRACKET (x2)
24 LV35264-001A BARRIER
25 QYSBST3005E TAP SCREW M3 x 5mm(x2)
26 LV34682-001A C.B BRACKET
27 QYSBSG3006ZA TAP SCREW M0 x #NEV
28 LV34784-001A SUPPORT BKT(B)
29 LV30225-0F4A SPACER
30 QYSBST3005E TAP SCREW M3 x 5mm
31 LV21638-002A HEAT SINK
32 LV43915-001A COOLING RUBBER (x3)
33 QYSBSG3006ZA TAP SCREW M0 x #NEV(x2)
34 LV34675-001A SHIELD BRACKET
35 QYSBSG3006ZA TAP SCREW M0 x #NEV(x6)
36 LV35043-002A TRANSISTOR HOLD
37 QYSBSG3006ZA TAP SCREW M0 x #NEV(x2)
38 LV30225-0U4A SPACER (x2)
39 QYSBSG3006ZA TAP SCREW M0 x #NEV
40 QYSBSG3006ZA TAP SCREW M0 x #NEV(x3)
41 QYSBSG3008E TAPPING SCREW 3mm x 8mm(x2)
42 QYSBSG3006ZA TAP SCREW M0 x #NEV(x2)
43 QYSBSG3006ZA TAP SCREW
44 QYSBSG3006ZA TAP SCREW M0 x #NEV(x5)
45 QYSBSG3006ZA TAP SCREW M0 x #NEV(x4)
46 QYSBSG3006ZA TAP SCREW M0 x #NEV
 47 QQR0491-001 FERRITE CORE TDK (GRAY)
48 VYSH101-009 SPACER
49 LV34676-001A FAN BRACKET
 50 QAR0312-002 FAN MOTER
51 LV35129-001A FAN COVER
52 QYSBSG3020ZA TAP SCREW M0.2 x #NEV(x2)
53 QYSBST3005E TAP SCREW M3 x 5mm(x2)
 54 QQT0446-003 POWER TRANSF
55 QYSDSTL4006E TAP SCREW M4 x 6mm(x4)
56 LV35044-002A DIVIDER
57 LV43929-001A COVER
58 LV21639-017A REAR PANEL
59 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
60 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
61 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
62 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x3)
63 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
64 QAU0347-001 TUNER
65 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
66 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x7)
 67 QMPN160-200-JD POWER CORD(EU) 2m BLACK
F10SB
 67 QMPK210-205-JN POWER CORD(EU) 2.05m BLACK
F10SE
,F10S
EN
 68 QZW0033-001 STRAIN RELIEF
 69 QQR0491-001 FERRITE CORE TDK (GRAY)
70 LV21640-004A/S/ TOP COVER
71 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x5)
72 QYSDSG3008NA TAP SCREW M0 x #NEV(x4)
73 LV43684-002A JOG KNOB ASSY (x2)
 74 QMF51W2-1R6-J8 FUSE F205
 75 QMF51W2-2R0-J8 FUSE F202 F203(x2)
 76 QMF51E2-R10-J1 FUSE F204
77 LV43550-004A LABEL
78 QYSBSG3008E TAPPING SCREW 3mm x 8mm(x7)
79 QUQ412-1612CJ FFC WIRE
80 QUQ412-1111CJ FFC WIRE
81 QUQ412-0914CJ CARD WIRE
82 QUQ412-2214CJ FFC WIRE
83 QUQ412-1115CJ FFC WIRE
84 E70306-006 HEAT SINK (x6)
85 E70306-001 HEAT SINK
 Symbol No. Part No. Part Name Description Local
