JVC RX-F10S Service Manual

3-5
Electrical parts list
Main board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
IC401 MN101C35DMF IC
IC402 GP1UM271XK IR DETECT UNIT 38kHz
Q201 UN221M-X DIGI TRANSISTOR
Q203 KTC3203/OY/-T TRANSISTOR
Q204 KTC3200/GL/-T TRANSISTOR
 Q205 KTA1046/Y/ TRANSISTOR
 Q207 KTA1046/Y/ TRANSISTOR
 Q208 2SD2394/EF/ TRANSISTOR
 Q209 2SD2394/EF/ TRANSISTOR
 Q210 2SD2394/EF/ TRANSISTOR
 Q211 2SD2394/EF/ TRANSISTOR
 Q212 2SD2394/EF/ TRANSISTOR
 Q213 2SD2394/EF/ TRANSISTOR
Q214 UN2111-X TRANSISTOR
Q215 UN2211-X TRANSISTOR
Q216 UN2111-X TRANSISTOR
Q217 UN2211-X TRANSISTOR
Q218 UN2111-X TRANSISTOR
Q219 UN2211-X TRANSISTOR
Q220 UN2215-X TRANSISTOR
Q221 UN2215-X TRANSISTOR
Q222 UN2215-X TRANSISTOR
Q223 UN2215-X TRANSISTOR
Q224 UN2215-X TRANSISTOR
Q225 UN221M-X DIGI TRANSISTOR
 Q226 2SD2394/EF/ TRANSISTOR
Q231 UN2211-X TRANSISTOR
Q401 UN2214-X TRANSISTOR
Q403 UN2110-X DIGI TRANSISTOR
Q404 UN2114-X TRANSISTOR
Q405 UN2114-X TRANSISTOR
Q406 UN2114-X TRANSISTOR
Q407 UN2114-X TRANSISTOR
Q408 UN2114-X TRANSISTOR
Q409 UN2114-X TRANSISTOR
Q410 UN2214-X TRANSISTOR
 D201 1A3G-T1 SI DIODE
 D202 1A3G-T1 SI DIODE
 D203 1A3G-T1 SI DIODE
 D204 1A3G-T1 SI DIODE
D205 MA111-X SI DIODE
D207 MTZJ6.2C-T2 Z DIODE
 D208 1A3G-T1 SI DIODE
 D209 1A3G-T1 SI DIODE
 D210 1A3G-T1 SI DIODE
 D211 1A3G-T1 SI DIODE
D212 1A3G-T1 SI DIODE
D213 1A3G-T1 SI DIODE
D215 MTZJ7.5C-T2 Z DIODE
D216 MTZJ7.5C-T2 Z DIODE
D217 MTZJ6.2C-T2 Z DIODE
D218 MTZJ10B-T2 Z DIODE
D219 MTZJ5.6C-T2 Z DIODE
D220 MTZJ5.6C-T2 Z DIODE
D221 MA111-X SI DIODE
D222 1A3G-T1 SI DIODE
D223 MTZJ27B-T2 Z DIODE
D224 MTZJ6.2C-T2 Z DIODE
D225 MA111-X SI DIODE
D227 MTZJ7.5C-T2 Z DIODE
 D231 1A3G-T1 SI DIODE
 D233 1A3G-T1 SI DIODE
 D234 1A3G-T1 SI DIODE
D235 MA111-X SI DIODE
D407 SLR-343VC-T LED
D408 SELU2E10C-P LED
D409 SELU2E10C-P LED
D410 MA111-X SI DIODE
D421 SLR-343VC-T LED
D422 SLR-343VC-T LED
D423 SLR-343VC-T LED
D424 SPR-325MVW/L/-T LED GREEN-RED
D425 SPR-325MVW/L/-T LED GREEN-RED
D426 SPR-325MVW/L/-T LED GREEN-RED
 C201 QCZ9104-472 C CAPACITOR 4700pF
C202 QFLC2AJ-472Z M CAPACITOR 4700pF 100V J
C203 QETN1JM-227Z E CAPACITOR 220uF 63V M
C205 NCB31HK-472X C CAPACITOR 4700pF 50V K
C206 QETN1CM-477Z E CAPACITOR 470uF 16V M
C207 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C208 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C209 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C210 QETM1EM-338 E CAPACITOR 3300uF 25V M
C211 QETM1EM-108 E CAPACITOR 1000uF 25V M
C212 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C213 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C214 QEKC1HM-105Z E CAPACITOR 1uF 50V M
C215 QETN1HM-476Z E CAPACITOR 47uF 50V M
 C217 QFZ9075-224 MPP CAPACITOR 0.22uF AC275V M
C221 QETN1EM-107Z E CAPACITOR 100uF 25V M
C222 QETN1EM-107Z E CAPACITOR 100uF 25V M
C223 QETN1EM-107Z E CAPACITOR 100uF 25V M
C224 QETM1EM-108 E CAPACITOR 1000uF 25V M
C225 QETN1EM-107Z E CAPACITOR 100uF 25V M
C226 QETN1EM-107Z E CAPACITOR 100uF 25V M
C227 QETN1EM-107Z E CAPACITOR 100uF 25V M
C231 QETN1CM-107Z E CAPACITOR 100uF 16V M
C241 QETN1HM-227Z E CAPACITOR 220uF 50V M
C242 QETN2AM-107Z E CAPACITOR 100uF 100V M
C243 QETN2AM-107Z E CAPACITOR 100uF 100V M
C251 QETN1CM-226Z E CAPACITOR 22uF 16V M
C401 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C402 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C405 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C406 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C407 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C408 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C409 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C410 QER61HM-475Z E CAPACITOR 4.7uF 50V M
C411 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C412 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C413 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C414 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C415 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C416 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C417 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C421 NCB31HK-102X C CAPACITOR 1000pF 50V K
C425 NDC31HJ-331X C CAPACITOR 330pF 50V J
C426 NDC31HJ-331X C CAPACITOR 330pF 50V J
C427 NDC31HJ-331X C CAPACITOR 330pF 50V J
C428 NDC31HJ-331X C CAPACITOR 330pF 50V J
C429 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C431 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C432 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C433 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C434 NCB31EK-104X C CAPACITOR 0.1uF 25V K
 R202 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R203 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R206 QRJ146J-821X UNF C RESISTOR 820 Ω 1/4W J
 R207 QRJ146J-120X UNF C RESISTOR 12 Ω 1/4W J
R208 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
 R209 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R210 QRZ9005-100X FUSI RESISTOR 10 Ω
 R211 QRK126J-562X UNF C RESISTOR 5.6k Ω 1/2W J
 R215 QRZ9005-100X FUSI RESISTOR 10 Ω
 R216 QRJ146J-152X UNF C RESISTOR 1.5k Ω 1/4W J
 R217 QRZ9006-8R2X FUSI RESISTOR 8.2 Ω
 R218 QRJ146J-152X UNF C RESISTOR 1.5k Ω 1/4W J
R219 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R220 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
