4.8 INITIAL SETTING VALUE OF SERVICE MENU
It is no requirement for adjustment of the part of the tables. Don' t change the values.
[SIGNAL BLOCK]
[WHITE BALANCE BLOCK]
Item Input signal Contents Variable range Initial value
S01
VIDEO
BRIGHT 000 ~ 255 137
S02 CONTRAST 000 ~ 127 059
S03 CHROMA(PAL) 000 ~ 127 064
S04 CHROMA(NTSC) 000 ~ 127 062
S05 PHASE(NTSC) 000 ~ 127 060
S06 COMPONENT CHROMA 000 ~ 127 080
S07
RGB
BRIGHT 000 ~ 127 076
S08 CONTRAST -128 ~ 000 ~ +127 -001
S09
VIDEO
UNDER SCAN BRIGHT -128 ~ 000 ~ +127 000
S10 UNDER SCAN CONTRAST -128 ~ 000 ~ +127 -009
S11 PHASE(PAL) 000 ~ 127 062(FIXED)
S12 COMPONENT PHASE 000 ~ 127 063(FIXED)
S13 VIDEO CONT TRACKING 000 ~ 031 016(FIXED)
Item Input signal Contents Variable range Initial value
W01
VIDEO
R CUTOFF 000 ~ 255 050
W02 G CUTOFF 000 ~ 255 050
W03 B CUTOFF 000 ~ 255 050
W04 R DRIVE (6500) 000 ~ 127 062
W05 B DRIVE (6500) 000 ~ 127 048
W06 R DRIVE (9300) 000 ~ 127 078
W07 B DRIVE (9300) 000 ~ 127 066
W08
COMPONENT
R CUTOFF -128 ~ 000 ~ +127 000
W09 G CUTOFF -128 ~ 000 ~ +127 000
W10 B CUTOFF -128 ~ 000 ~ +127 000
W11 R DRIVE (6500) -128 ~ 000 ~ +127 000
W12 B DRIVE (9300) -128 ~ 000 ~ +127 000
W13 R DRIVE (6500) -128 ~ 000 ~ +127 000
W14 B DRIVE (9300) -128 ~ 000 ~ +127 000
W15
RGB
R CUTOFF -128 ~ 000 ~ +127 000
W16 G CUTOFF -128 ~ 000 ~ +127 000
W17 B CUTOFF -128 ~ 000 ~ +127 000
W18 R DRIVE (6500) -128 ~ 000 ~ +127 000
W19 B DRIVE (9300) -128 ~ 000 ~ +127 000
W20 R DRIVE (6500) -128 ~ 000 ~ +127 000
W21 B DRIVE (9300) -128 ~ 000 ~ +127 000
W22
VIDEO
UNDER SCAN R CUTOFF -128 ~ 000 ~ +127 000
W23 UNDER SCAN G CUTOFF -128 ~ 000 ~ +127 000
W24 UNDER SCAN B CUTOFF -128 ~ 000 ~ +127 000
-
