JVC TM-H150CG/E

1-24 (No.YA068)
[DEFLECTION BLOCK]
Item
Aspect ratio/
Scan size
Vertical
frequency
Contents Variable range Initial value
D01
4:3
NORMAL
50Hz
HORIZONTAL POSITION 000 ~ 031 012
D02 HORIZONTAL SIZE 000 ~ 063 040
D03 VERTICAL POSITION 000 ~ 127 041
D04 VERTICAL SIZE 000 ~ 127 058
D05 VERTICAL LINEARITY 000 ~ 031 025
D06 VERTICAL S-CORRECTION 000 ~ 063 040
D07 SIDEPIN PARABOLA 000 ~ 063 030
D08 SIDEPIN CORNER 000 ~ 031 018
DA1
4:3
NORMAL
60Hz
HORIZONTAL POSITION -032 ~ 000 ~ +031 +002
DA2 HORIZONTAL SIZE -064 ~ 000 ~ +063 -4
DA3 VERTICAL POSITION -128 ~ 000 ~ +127 +002
DA4 VERTICAL SIZE -128 ~ 000 ~ +127 000
DA5 VERTICAL LINEARITY -032 ~ 000 ~ +031 -1
DA6 VERTICAL S-CORRECTION -064 ~ 000 ~ +063 000
DA7 SIDEPIN PARABOLA -064 ~ 000 ~ +063 +001
DA8 SIDEPIN CORNER -032 ~ 000 ~ +031 +001
DB1
16:9
NORMAL
50Hz
HORIZONTAL POSITION -032 ~ 000 ~ +031 000
DB2 HORIZONTAL SIZE -064 ~ 000 ~ +063 000
DB3 VERTICAL POSITION -128 ~ 000 ~ +127 000
DB4 VERTICAL SIZE -128 ~ 000 ~ +127 -28
DB5 VERTICAL LINEARITY -032 ~ 000 ~ +031 000
DB6 VERTICAL S-CORRECTION -064 ~ 000 ~ +063 000
DB7 SIDEPIN PARABOLA -064 ~ 000 ~ +063 -11
DB8 SIDEPIN CORNER -032 ~ 000 ~ +031 000
DC1
16:9
NORMAL
60Hz
HORIZONTAL POSITION -032 ~ 000 ~ +031 000
DC2 HORIZONTAL SIZE -064 ~ 000 ~ +063 000
DC3 VERTICAL POSITION -128 ~ 000 ~ +127 000
DC4 VERTICAL SIZE -128 ~ 000 ~ +127 -27
DC5 VERTICAL LINEARITY -032 ~ 000 ~ +031 000
DC6 VERTICAL S-CORRECTION -064 ~ 000 ~ +063 -1
DC7 SIDEPIN PARABOLA -064 ~ 000 ~ +063 -12
DC8 SIDEPIN CORNER -032 ~ 000 ~ +031 -1
DD1
4:3
UNDER
SCAN
50Hz
HORIZONTAL POSITION -032 ~ 000 ~ +031 000
DD2 HORIZONTAL SIZE -064 ~ 000 ~ +063 -7
DD3 VERTICAL POSITION -128 ~ 000 ~ +127 000
DD4 VERTICAL SIZE -128 ~ 000 ~ +127 -3
DD5 VERTICAL LINEARITY -032 ~ 000 ~ +031 000
DD6 VERTICAL S-CORRECTION -064 ~ 000 ~ +063 000
DD7 SIDEPIN PARABOLA -064 ~ 000 ~ +063 -19
DD8 SIDEPIN CORNER -032 ~ 000 ~ +031 -1
DE1
4:3
UNDER
SCAN
60Hz
HORIZONTAL POSITION -032 ~ 000 ~ +031 000
DE2 HORIZONTAL SIZE -064 ~ 000 ~ +063 -6
DE3 VERTICAL POSITION -128 ~ 000 ~ +127 000
DE4 VERTICAL SIZE -128 ~ 000 ~ +127 -2
DE5 VERTICAL LINEARITY -032 ~ 000 ~ +031 000
DE6 VERTICAL S-CORRECTION -064 ~ 000 ~ +063 000
DE7 SIDEPIN PARABOLA -064 ~ 000 ~ +063 -20
DE8 SIDEPIN CORNER -032 ~ 000 ~ +031 -2
DF7
16:9
UNDER SCAN
50Hz
SIDEPIN PARABOLA -064 ~ 000 ~ +063 +007
DF8 SIDEPIN CORNER -032 ~ 000 ~ +031 000
DG7
16:9
UNDER SCAN
60Hz
SIDEPIN PARABOLA -064 ~ 000 ~ +063 +008
DG8 SIDEPIN CORNER -032 ~ 000 ~ +031 +001
