JVC UX-S59 - Removing the Front Cabinet

(No.MB409)1-13
3.1.16 Removing the front cabinet
(See Fig.23 to 25)
(1) Removing the two screws O1. (See Fig.23, 24)
(2) Disengage the claws O2 on both side of the bottom plate.
(See Fig.23, 24)
(3) Pull out two connect wire O4 separate on CD mechanism
cover and bottom plate. (See Fig.24)
(4) Remove the two screws O3. (See Fig.25)
Fig.23
Fig.24
Fig.25
Front cabine assembly
O1
O2
O4
O4
O1
O2
O3
