JVC UX-S59 Service Manual

3-10
Power trans board
Block No. [0][3]
CD board
Block No. [0][4]
 Symbol No. Part No. Part Name Description Local
IC901 78L05 IC BI101851
Q903 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
D901 1N4001 DIODE BI31N4001M0006
D902 1N4001 DIODE BI31N4001M0006
D903 1N4001 DIODE BI31N4001M0006
D904 1N4001 DIODE BI31N4001M0006
D905 1N4001 DIODE BI31N4001M0006
C903 BICH104500KM019 CAPACITOR 0.1uF 50V
C904 BICE477250MP015 E CAPACITOR 470uF 25V
C905 BICE227100MP015 E CAPACITOR 220uF
C906 BICE476160MP015 E CAPACITOR 47uF 16V
C907 BICH472500KM019 CAPACITOR 4700pF
R902 BIRC3320085M000 C RESISTOR 3.3K
Ω 1/8W
R903 BIRC2220085M000 C RESISTOR 2.2K
Ω 1/8W
R905 BIRC3300085M000 C RESISTOR 33
Ω 1/8W
R906 BIRC4720085M000 C RESISTOR 4.7K
Ω 1/8W
R907 BIRC1220085M000 C RESISTOR 1.2K
Ω 1/8W
 L901 BI2601102 LINE FILTER
BN903 BI12P60170V WIRE 6P
CN901 BI12S200691V CONNECTOR 2P
CN902 BI12S200691V CONNECTOR 2P
 PT902 BI2110410070001 POWER TRANS 2598A
 RY901 BI8RL00171V RELAY KTC3199GR
XXXXX BI251393G01V POWER PCB PT PCB
 Symbol No. Part No. Part Name Description Local
IC701 S1L9226 IC BI116431
IC703 IP4001S IC BI118471
IC801 S5L9279 IC BI116401
IC802 K4S161622H-UC60 IC BI117401V
IC803 BH18FB1WG IC BI118171
IC871 MN101C61G IC BI118121
IC872 BR93L56RF IC BI118251
Q701 KTA1266GR TRANSISTOR BI2KTA1266GP000
Q703 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q762 DTC114TK TRANSISTOR BI2DTC114TKA011
Q871 DTC114TK TRANSISTOR BI2DTC114TKA011
D762 1SS133 FR DIODE
BI31SS133M000V
7
C701 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C702 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C703 BICC102500JA041 C CAPACITOR 1000pF 50V
C704 BICE476160MP111 E CAPACITOR 47uF 16V
C705 BICC102500JA041 C CAPACITOR 1000pF 50V
C706 BICC102500JA041 C CAPACITOR 1000pF 50V
C707 BICC103250KA042 C CAPACITOR 0.01uF 25V
C708 BICC473250KA042 C CAPACITOR 0.047uF 25V
C709 BICE227063MP111 E CAPACITOR 220uF 6.3V
C710 BICE107100MP111 E CAPACITOR 100uF 10V
C711 BICC040500CA041 C CAPACITOR 4pF 50V
C712 BICC100500DA041 C CAPACITOR 10pF 50V
C713 BICC682500KA042 C CAPACITOR 6800pF 50V
C714 BICC103250KA042 C CAPACITOR 0.01uF 25V
C715 BICE475500MP111 E CAPACITOR 4.7uF 50V
C716 BICC10450KA042 C CAPACITOR 0.1uF 50V
C717 BICC10450KA042 C CAPACITOR 0.1uF 50V
C718 BICC102500JA041 C CAPACITOR 1000pF 50V
C719 BICC10450KA042 C CAPACITOR 0.1uF 50V
C720 BICC333250KA042 C CAPACITOR 0.033uF 25V
C721 BICC474100KA042 C CAPACITOR 0.47uF 10V
C722 BICC474100KA042 C CAPACITOR 0.47uF 10V
C723 BICC332500KA042 C CAPACITOR 3300pF 50V
C724 BICC103250KA042 C CAPACITOR 0.01uF 25V
C725 BICC683160KA042 C CAPACITOR 0.068uF 16V
C726 BICE106100MP111 E CAPACITOR 10uF 10V
C727 BICC823160KA042 C CAPACITOR 0.082uF 16V
C728 BICC331500JA041 C CAPACITOR 330pF 50V
C729 BICC102500JA041 C CAPACITOR 1000pF 50V
C730 BICC222500KA042 C CAPACITOR 2200pF 50V
C731 BICC333250KA042 C CAPACITOR 0.033uF 25V
C732 BICC10450KA042 C CAPACITOR 0.1uF 50V
C733 BICC10450KA042 C CAPACITOR 0.1uF 50V
C734 BICC101500JA041 C CAPACITOR 100pF 50V
C735 BICC101500JA041 C CAPACITOR 100pF 50V
C736 BICC101500JA041 C CAPACITOR 100pF 50V
C737 BICC101500JA041 C CAPACITOR 100pF 50V
C738 BICC101500JA041 C CAPACITOR 100pF 50V
C739 BICC101500JA041 C CAPACITOR 100pF 50V
C740 BICC101500JA041 C CAPACITOR 100pF 50V
C741 BICC391500JA041 C CAPACITOR 390pF 50V
C742 BICC391500JA041 C CAPACITOR 390pF 50V
C743 BICC391500JA041 C CAPACITOR 390pF 50V
C744 BICC391500JA041 C CAPACITOR 390pF 50V
C755 BICC102500JA041 C CAPACITOR 1000pF 50V
C756 BICC102500JA041 C CAPACITOR 1000pF 50V
C761 BICE477100MP015 E CAPACITOR 470uF 10V
C762 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C763 BICE107100MP111 E CAPACITOR 100uF 10V
C803 BICE107100MP111 E CAPACITOR 100uF 10V
C804 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C805 BICC270500JA041 C CAPACITOR 27pF 50V
C806 BICC270500JA041 C CAPACITOR 27pF 50V
C807 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C808 BICE107100MP111 E CAPACITOR 100uF 10V
C809 BICC10450KA042 C CAPACITOR 0.1uF 50V
C810 BICC122500KA042 C CAPACITOR 1200pF 50V
C811 BICC122500KA042 C CAPACITOR 1200pF 50V
C812 BICC122500KA042 C CAPACITOR 1200pF 50V
C813 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C814 BICE107100MP111 E CAPACITOR 100uF 10V
C815 BICE107100MP111 E CAPACITOR 100uF 10V
C816 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C817 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C818 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C819 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C820 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C821 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C822 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C823 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C825 BICC103250KA042 C CAPACITOR 0.01uF 25V
C826 BICE106100MP111 E CAPACITOR 10uF 10V
C827 BICE106100MP111 E CAPACITOR 10uF 10V
C835 BICC100500DA041 C CAPACITOR 10pF 50V
C841 BICC102500KA042 C CAPACITOR 1000pF 50V
C842 BICC330500JA041 C CAPACITOR 33pF 50V
C843 BICC330500JA041 C CAPACITOR 33pF 50V
C844 BICC330500JA041 C CAPACITOR 33pF 50V
C871 BICC103250KA042 C CAPACITOR 0.01uF 25V
C872 BICC104500ZA043 C CAPACITOR 0.1uF 50V
C873 BICC150500JA041 C CAPACITOR 15pF 50V
C874 BICC101500JA041 C CAPACITOR 100pF 50V
C875 BICC330500JA041 C CAPACITOR 33pF 50V
C876 BICC470500JA041 C CAPACITOR 47pF 50V
C877 BICC470500JA041 C CAPACITOR 47pF 50V
C878 BICC470500JA041 C CAPACITOR 47pF 50V
C880 BICC470500JA041 C CAPACITOR 47pF 50V
C881 BICC470500JA041 C CAPACITOR 47pF 50V
C882 BICC10450KA042 C CAPACITOR 0.1uF 50V
C883 BICC104500ZA043 C CAPACITOR 0.1uF 50V
R701 BIRC0820105A005 C RESISTOR 8.2
Ω 1/10W
R702 BIRC1840105A005 C RESISTOR 180K
Ω 1/10W
R703 BIRC3930105A005 C RESISTOR 39K
Ω 1/10W
R704 BIRC3930105A005 C RESISTOR 39K
Ω 1/10W
 Symbol No. Part No. Part Name Description Local
