UX-T77 UX-T77
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 VJG1473-023 FRONT PANEL 1 MIPS SPRAY*1 S*
2 VXP3867-005 PUSH BUTTON(A) 1 ABS
3 VXP5352-005 PUSH BUTTON(B) 1 ABS
4 VXP5353-005 PUSH BUTTON(C) 1 ABS
5 VXP5358-006 SNOOZE BUTTON 1 ABS
6 VJK4493-001SC LENS(STANDBY) 1
7 VJK4504-001 REMOCON LENS 1
8 QYSBSF2608Z T.SCREW 2 FOR F.P+PWB
9 QYSBSF3008Z SCREW 2 BUTTON+PWB
10 QYSBSF2608Z T.SCREW 2 FOR F.P+BUTTON
11 VXL4453-005 MULTI JOG DIAL 1 ABS
12 VYH3982-001 LAMP CASE 1 SPTE T0.4
13 VYTT704-001 LCD FILTER 1 FOR LCD
14 VJT4241-002 LCD LENS 1 PMMA SILK*1
16 E406971-001SM JVC MARK 1 GOLD
18 VYH8160-005 BUTTON COVER 1 SILK*1
19 VKW5306-001 COMP.SPRING 2
20 VYH3983-001 DOOR HOLDER 1 EGC T1
21 VYH8149-001 EJECT LEVER 1 EGC T1.2
22 VXQ4125-005 EJECT KNOB 1 ABS
23 QYSBSF2608Z T.SCREW 1 FOR E.LVR+E.KNO
24 VKZ4323-002 SCREW 2 D.HOLDER+E.LEVE
25 VKW3002-274 TENSION SPRING 1 FOF E.LEVER
26 VYH7347-001 EJECT ARM 1 POM
27 VKZ4341-001 SPECIAL SCREW 1 FOR EJECT ARM
28 VKW4938-001 TORTION SPRING 1 FOR EJECT ARM
29 QYSBSF3008Z SCREW 2 F.P+D.HOLDER
30 VKY4180-001 CASSETTE SPRING 2
31 VYH5601-001 GEAR 1
32 VKW5295-001 DOOR SPRING 1 SUS
33 LV20361-002A CASSETTE DOOR 1 MIPS SPRAY*1
34 LV40937-002A DOOR LENS 1 PMMA SILK*2
36 ----------- CASSETTE MECHA 1 SLC
37 VKL7850-203 EJECT SAFTY(R) 1
38 VKW5258-003 TORSION SPRING 1
39 VMA4723-001 SHIELD 1
40 QYSBSF3010Z SCREW 2 F.PANEL+MECHA
41 VYH8183-001 BRACKET 1 FOR CASSETTE DO
42 QYSBST3008Z T.SCREW 2 DOOR HOL+MECHA
43 VYH1263-001 BOTTOM CHASSIS 1 EGC T0.8
44 QYSBST4006Z T.SCREW 4 CHASSIS+TRANS
45 VYH3984-001 JACK HOLDER 1 ABS FOR
46 QYSBSF3010Z SCREW 1 PWB+JACK HOL
47 VYH8153-001 RADIATION 1 AL e-j--
48 QYSBST3012Z T.SCREW 4 RADI+IC
49 QYSBST3006Z T.SCREW 1 RADI+CHASSIS
50 QYSBST3006Z T.SCREW 1 MAIN PWB+CHASSI
51 QYSBST3006Z T.SCREW 1 TUNER PWB+CHASS
(General assembly)
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
52 VYH3987-001SC IC HOLDER 1 SPTE T0.4
54 VMA3239-001 SHIELD 1
55 VMA4720-001 BARRIER 1
56 --------- CD MECHA 1
57 VJD5410-306 PICK COVER 1
58 QYSDSF2006M SCREW 4 CD MECHA+P.COVE
59 FMYH4003-001J INSULATOR 2
60 FMYH4003-002J INSULATOR 2
61 VYH8089-001SC CD MECHA HOLDER 1
62 VYH8089-002SC CD MECHA HOLDER 1
63 QYSBSF3010Z SCREW 4 CD CASE+M.HOLDE
64 VMA4692-002SC SHIELD 1 FOR CD MECHA WI
65 VJD1216-003 CD CASE 1 MIPS T2.5 EMBOS
67 VYH4769-002SS GEAR 1
68 VKW5276-001 CD DOOR SPRING 1 SUS
69 VYH8152-001 LOCK LEVER 1 POM
70 VXP5354-006 CD EJECT KNOB 1 ABS
71 VJT2385-007 CD DOOR 1 ABS HOT STAMP
72 VJT3392-002 CD LENS 1 PMMA
73 VJT4245-005 CD ORNAMENT 1
74 VYH3726-002SS CLAMPER 1 ABS
75 VYH7313-003 MAGNET 1
76 VYH7677-201 YOKE 1 EGC T0.8
77 QYSDSF2606Z SCREW 1 FOR CLAMPER
78 QYSBSF3010Z SCREW 4 CD PWB+CD CASE
79 VMA4721-002 SHIELD 1
80 PU59915-105 SPACER 1
81 QYSSST3008Z SCREW 2 CHASSIS+F.PANEL
82 VJD2488-008 SIDE PANEL(L) 1
83 VJD2489-008 SIDE PANEL 1
85 VJG1477-027 REAR PANEL 1 PS -t- k-c-h
86 QYSBSF3010Z SCREW 7
88 QYSSST3008Z SCREW 2 FOR R.P+CHASSIS
90 LV31059-004A NAME PLATE 1
91 QUQ910-1507AJ FFC WIRE 1
92 QUQB12-0508CJ FFC WIRE 1
93 QUQB12-0914CJ FFC WIRE 1
94 QUQB12-1020CJ FFC WIRE 1
95 QUQB12-0716CJ FFC WIRE 1
96 QUQB12-1106DJ FFC WIRE 1
97 QUQB12-1020CJ FFC WIRE 1
98 SA-Y-6-06-PH-06 SA-PH CONNECTOR 1
99 SC-J-2-10-EH-02 SC-EH WIRE 1
100 QMF51E2-R40-J1 FUSE
A
1 F901
101 QMF51E2-5R0-J1 FUSE
A
1 F903
102 VTP66J2-12L POWER TRANS
A
1 T901
(General assembly)
