JVC UX-T77 - Electrical Parts List

UX-T77
3-11
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
C 901 QFLC1HJ-104Z M CAPACITOR
A
.10MF 5% 50V
C 902 QFLC1HJ-104Z M CAPACITOR
A
.10MF 5% 50V
C 903 QFLC1HJ-104Z M CAPACITOR
A
.10MF 5% 50V
C 904 QFLC1HJ-104Z M CAPACITOR
A
.10MF 5% 50V
CN301 QGB1214J1-20S CONNECTOR
CN302 QGB1214J1-06S CONNECTOR
CN303 QGF1205C1-10 CONNECTOR
CN304 QGF1205C1-07 CONNECTOR
CN901 QGA2501C4-02 CONNECTOR
C1001 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C1002 QDX31EM-104Z C.CAPA I.M
C1003 QDX31EM-104Z C.CAPA I.M
C1006 QTE1C03-106Z E CAPACITOR
C1021 QFN31HJ-823Z M CAPACITOR .082MF 5% 50V
C1022 QFN31HJ-823Z M CAPACITOR .082MF 5% 50V
C1025 QTE1A03-226Z E CAPACITOR
C1026 QFVJ1HJ-334Z M.CAPACITOR .33MF 5% 50V
C1051 QCS11HJ-100 C CAPACITOR 10PF 5% 50V
C1053 QTE1C03-106Z E CAPACITOR
C1054 QFN31HJ-392Z M.CAPA. I.M 3900PF 5% 50V
C1055 QETC1EM-475Z-JB E CAPACITOR 4.7MF 20% 25V
C1056 QTE1C03-106Z E CAPACITOR
C1070 QETC1EM-475Z-JB E CAPACITOR 4.7MF 20% 25V
C1082 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C1083 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C1084 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V
C2001 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C2002 QDX31EM-104Z C.CAPA I.M
C2003 QDX31EM-104Z C.CAPA I.M
C2006 QTE1C03-106Z E CAPACITOR
C2021 QFN31HJ-823Z M CAPACITOR .082MF 5% 50V
C2022 QFN31HJ-823Z M CAPACITOR .082MF 5% 50V
C2025 QTE1A03-226Z E CAPACITOR
C2026 QFVJ1HJ-334Z M.CAPACITOR .33MF 5% 50V
C2051 QCS11HJ-100 C CAPACITOR 10PF 5% 50V
C2053 QTE1C03-106Z E CAPACITOR
C2054 QFN31HJ-392Z M.CAPA. I.M 3900PF 5% 50V
C2055 QETC1EM-475Z-JB E CAPACITOR 4.7MF 20% 25V
C2056 QTE1C03-106Z E CAPACITOR
C2070 QETC1EM-475Z-JB E CAPACITOR 4.7MF 20% 25V
C2082 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C2083 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C2084 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V
C3001 QETM1EM-688 E CAPACITOR 6800MF 20% 25V
C3002 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C3003 QETC1CM-107Z-JB E.CAPACITOR 100MF 20% 16V
C3004 QETC1AM-337Z-JB E CAPACITOR 330MF 20% 10V
C3005 QETC1AM-336Z-JB E CAPACITOR 33MF 20% 10V
C3006 QETC1HM-225Z-JB E CAPACITOR 2.2MF 20% 50V
C3010 QETC1HM-684Z E.CAPACITOR .68MF 20% 50V
C3011 QDYB1CM-103Y C.CAPACITOR
C3021 QETC1CM-476Z-JB E CAPACITOR 47MF 20% 16V
C3022 QETC1AM-476Z-JB E CAPACITOR 47MF 20% 10V
C3031 QETC1HM-105Z-JB E CAPACITOR 1.0MF 20% 50V
C3032 QETC1HM-105Z-JB E CAPACITOR 1.0MF 20% 50V
C3033 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C3034 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C3035 QETC1HM-105Z-JB E CAPACITOR 1.0MF 20% 50V
C3036 QETC1CM-106Z-JB E CAPACITOR 10MF 20% 16V
C3037 QETC1CM-106Z-JB E CAPACITOR 10MF 20% 16V
C3041 QETC1EM-106Z-JB CAPACITOR 10MF 20% 25V
C3051 QETC1CM-476Z-JB E CAPACITOR 47MF 20% 16V
C3052 QETC1CM-476Z-JB E CAPACITOR 47MF 20% 16V
C3070 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C3081 QETC1CM-227Z-JB E CAPACITOR 220MF 20% 16V
C3083 QETC1HM-474Z-JB E CAPACITOR .47MF 20% 50V
C3084 QETC1HM-474Z-JB E CAPACITOR .47MF 20% 50V
C3085 QETC1HM-474Z-JB E CAPACITOR .47MF 20% 50V
C3086 QETC1EM-106Z-JB CAPACITOR 10MF 20% 25V
C3087 QETC1HM-224Z-JB E CAPACITOR .22MF 20% 50V
C9001 QETC1CM-226Z-JB E CAPACITOR 22MF 20% 16V
C9003 QDYB1CM-103Y C.CAPACITOR
C9004 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C9201 QETC1CM-476Z-JB E CAPACITOR 47MF 20% 16V
C9202 QDYB1CM-103Y C.CAPACITOR
C9203 QETC1CM-106Z-JB E CAPACITOR 10MF 20% 16V
C9301 QETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C9302 QETC1HM-475Z-JB E CAPACITOR 4.7MF 20% 50V
C9501 QETC1AM-477Z-JB E CAPACITOR 470MF 20% 10V
D 901 6A10E2 SI DIODE
A
D 902 6A10E2 SI DIODE
A
D 903 6A10E2 SI DIODE
A
D 904 6A10E2 SI DIODE
A
D 905 6A10E2 SI DIODE
A
D3021 MTZJ4.3B-T2 ZENER DIODE
D3031 1SS254-T2 SI DIODE
D3032 1SS254-T2 SI DIODE
D3033 1SS254-T2 SI DIODE
D3034 1SS254-T2 SI DIODE
D3070 MTZJ6.8B-T2 NER DIODE
D9001 1SS254-T2 SI DIODE
D9002 MTZJ8.2C-T2 ZENER DIODE
D9003 MTZJ10A-T2 ZENER DIODE
D9102 1SR35-100A-T5 SI DIODE
D9201 MTZJ4.3B-T2 ZENER DIODE
D9301 MTZJ3.9B-T2 Z DIODE IM
D9302 1SS254-T2 SI DIODE
D9303 1SS254-T2 SI DIODE
D9501 1SS254-T2 SI DIODE
IC 31 LA4705NA IC
A
IC 32 BA15218N IC
IC 35 BA15218N IC
IC 38 BH3852S IC
J 901 QNC0001-001 AC INRET
A
J 902 QNA0016-001 DC JACK
A
J3001 QNN0090-001 PIN JACK KUNMING HSP-242
J3002 QNB0035-001 SPK TERMINAL KUNMIG HSP-324V
J3003 QNS0072-001 HEADPHONE JACK
K9401 QQR0786-001Z INDUCTOR
L3070 QQR0868-001Z INDUCTOR
Q
1010 2SD2144S/VW/-T TRANSISTOR
Q
1031 KTC3199/GL/-T TRANSISTOR
Q
1041 2SC2001/LK/-T TRANSISTOR
Q
1070 KTC3199/GL/-T TRANSISTOR
Q
2010 2SD2144S/VW/-T TRANSISTOR
Q
2031 KTC3199/GL/-T TRANSISTOR
Q
2041 2SC2001/LK/-T TRANSISTOR
Q
2070 KTC3199/GL/-T TRANSISTOR
Q
3010 KTC3199/GL/-T TRANSISTOR
Q
3041 KRA101M-T TR I/M
Q
3070 KRA101M-T TR I/M
Q
9001 2SB1565/EF/ TRANSISTOR
A
Q
9002 KTC3199/GL/-T TRANSISTOR
Q
9003 KTA1267/YG/-T TRANSISTOR
Q
9004 KRC114M-T TR I.M *
Q
9005 DTA144TSA-T D.TR.I.M
(Main board)
