Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
Q
9006 KTC3199/GL/-T TRANSISTOR
Q
9007 KTC3199/GL/-T TRANSISTOR
Q
9201 2SA1359/OY/ TRANSISTOR
A
Q
9202 KTC3199/GL/-T TRANSISTOR
Q
9301 KTA1267/YG/-T TRANSISTOR
Q
9302 KTC3199/GL/-T TRANSISTOR
Q
9501 2SC2001/LK/-T TRANSISTOR
R1001 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R1002 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R1003 QRE141J-151Y C RESISTOR 150 5% 1/4W
R1004 QRE141J-471Y C RESISTOR 470 5% 1/4W
R1011 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R1012 QRE141J-623Y C RESISTOR 62K 5% 1/4W
R1013 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1014 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R1015 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1022 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R1023 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R1024 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R1026 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1027 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1028 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1029 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1031 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1032 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1033 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1041 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1051 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R1052 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1054 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1055 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R1056 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1057 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R1058 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R1070 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R1071 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1072 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R1073 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1074 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R1082 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R1083 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R1091 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R1093 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R2001 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R2002 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R2003 QRE141J-151Y C RESISTOR 150 5% 1/4W
R2004 QRE141J-471Y C RESISTOR 470 5% 1/4W
R2011 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R2012 QRE141J-623Y C RESISTOR 62K 5% 1/4W
R2013 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R2014 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R2015 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R2022 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R2023 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R2024 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R2026 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R2027 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R2028 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R2029 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R2031 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R2032 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R2033 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R2041 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R2051 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R2052 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R2054 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R2055 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R2056 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R2057 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R2058 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R2070 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R2071 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R2072 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R2073 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R2074 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R2082 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R2083 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R2091 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R2093 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3001 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3010 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3021 QRE141J-101Y C RESISTOR 100 5% 1/4W
R3022 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R3031 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R3032 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R3033 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R3034 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R3035 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R3036 QRE141J-513Y C RESISTOR 51K 5% 1/4W
R3051 QRE141J-101Y C RESISTOR 100 5% 1/4W
R3052 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R3053 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R3081 QRE141J-101Y C RESISTOR 100 5% 1/4W
R3082 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R3083 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R3084 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R9001 QRE141J-1R0Y C RESISTOR 1.0 5% 1/4W
R9002 QRE141J-1R0Y C RESISTOR 1.0 5% 1/4W
R9003 QRE141J-1R0Y C RESISTOR 1.0 5% 1/4W
R9004 QRE141J-471Y C RESISTOR 470 5% 1/4W
R9005 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R9006 QRE141J-242Y C RESISTOR 2.4K 5% 1/4W
R9007 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R9008 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R9012 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9013 QRE141J-471Y C RESISTOR 470 5% 1/4W
R9014 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9016 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9017 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9018 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R9019 QRE141J-391Y C RESISTOR 390 5% 1/4W
R9021 QRZ9005-680X F.RES I/M 68 1/0W
R9201 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R9202 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R9203 QRE141J-221Y C RESISTOR 220 5% 1/4W
R9301 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R9302 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R9303 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R9304 QRE141J-390Y C RESISTOR 39 5% 1/4W
R9401 QRZ9006-4R7X F RESISTOR
A
4.7 1/0W
R9501 QRE141J-221Y C RESISTOR 220 5% 1/4W
Z 901 QNG0003-001Z FUSE CLIP
Z 903 QNG0003-001Z FUSE CLIP
Z 911 QNG0003-001Z FUSE CLIP
Z 913 QNG0003-001Z FUSE CLIP
(Main board)
