JVC UX-T77 - Page 56

UX-T77
3-13
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
C 604 QEK61AM-107Z-JB E.CAPA I.M 100MF 20% 10V
C 605 QETC1EM-106Z-JB CAPACITOR 10MF 20% 25V
C 606 QDGB1HK-102Y C CAPACITOR
C 607 QDGB1HK-102Y C CAPACITOR
C 608 QETC1HM-105Z-JB E CAPACITOR 1.0MF 20% 50V
C 609 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C 610 QFN31HJ-273Z M CAPACITOR .027MF 5% 50V
C 611 QDXB1CM-472Y C CAPACITOR
C 612 QDYB1CM-103Y C.CAPACITOR
C 613 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 614 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 615 QDVB1EZ-223Y C CAPACITOR
C 616 QDVB1EZ-223Y C CAPACITOR
C 617 QDVB1EZ-223Y C CAPACITOR
C 618 QDXB1CM-222Y C.CAPA IM
C 619 QCBB1HK-271Y C CAPACITOR 270PF 10% 50V
C 620 QCBB1HK-181Y C CAPACITOR 180PF 10% 50V
C 622 QETC1AM-476Z-JB E CAPACITOR 47MF 20% 10V
C 623 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 624 QDVB1EZ-223Y C CAPACITOR
C 628 QDX31EM-473Z C.CAPACITOR
C 629 QETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C 631 QETC1AM-477Z-JB E CAPACITOR 470MF 20% 10V
C 632 QEK61AM-107Z-JB E.CAPA I.M 100MF 20% 10V
C 633 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C 634 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C 635 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C 636 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C 637 QDYB1CM-822Y C.CAPA IM
C 651 QCSB1HJ-120Y C CAPACITOR 12PF 5% 50V
C 652 QCS11HJ-150 C CAPACITOR 15PF 5% 50V
C 653 QDVB1EZ-223Y C CAPACITOR
C 655 QDX31EM-473Z C.CAPACITOR
C 661 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 662 QDVB1EZ-223Y C CAPACITOR
C 663 QFN31HJ-223Z M CAPACITOR .022MF 5% 50V
C 664 QDVB1EZ-223Y C CAPACITOR
C 665 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 671 QDXB1CM-152Y C.CAPA IM
C 672 QDXB1CM-152Y C.CAPA IM
C 673 QTE1C05-227 E CAPACITOR
C 674 QDVB1EZ-223Y C CAPACITOR
C 675 QDGB1HK-102Y C CAPACITOR AG-DG
C 676 QDGB1HK-102Y C CAPACITOR AG-DG
C 691 QCBB1HK-151Y C CAPACITOR DENGEN NOISE
C 692 QCBB1HK-151Y C CAPACITOR DENGEN NOISE
C 693 QCBB1HK-151Y C CAPACITOR DENGEN NOISE
CN601 QGF1008F1-15 21-41 CONNECTOR TO RF
CN603 QGF1205F1-07 CONNECTOR TO AUDIO
CN604 QGF1205F1-11 CONNECTOR TO MICON
CN605 QGA2501F1-03 CONNECTOR TO DIGITAL OUT
D 661 1SS254-T2 SI DIODE
IC601 AN8806SB IC RF AMP
IC602 BA6897FP IC
IC603 MN35510 IC 1CHIP PROCESSER
Q
601 2SA952/LK/-T TRANSISTOR
Q
631 2SA952/LK/-T TRANSISTOR
R 601 QRE141J-113Y C RESISTOR 11K 5% 1/4W
R 603 QRE141J-125Y C RESISTOR 1.2M 5% 1/4W
R 605 QRE141J-274Y C RESISTOR 270K 5% 1/4W
R 606 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 607 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 609 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 610 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 612 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 613 QRE141J-121Y C RESISTOR 120 5% 1/4W
R 614 QRE141J-100Y C RESISTOR 10 5% 1/4W
R 615 QRE141J-120Y C RESISTOR 12 5% 1/4W
R 616 QRE141J-910Y C RESISTOR 91 5% 1/4W
R 621 QRE141J-330Y C RESISTOR 33 5% 1/4W
R 622 QRE141J-330Y C RESISTOR 33 5% 1/4W
R 623 QRE141J-330Y C RESISTOR 33 5% 1/4W
R 631 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 632 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 633 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 634 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 641 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 642 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 643 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R 644 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 645 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 646 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 647 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 651 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 652 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 653 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 654 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 655 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 659 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 661 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 662 QRE141J-155Y C RESISTOR 1.5M 5% 1/4W
R 663 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R 664 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 666 QRE141J-220Y C RESISTOR 22 5% 1/4W
R 671 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 672 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 681 QRE141J-474Y C RESISTOR 470K 5% 1/4W
X 651 QAX0378-001 RESONATOR 16.9344MHZ
(Micon board)
Item
Parts number Parts name Area
Remarks
A
