UX-T77
3-14
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
C 1 NCB21HK-223X C CAPACITOR
C 3 NCB21EK-473X C CAPACITOR
C 4 NCB21HK-103X C CAPACITOR
C 5 QEK61CM-106Z-JB E.CAPA I.M 10MF 20% 16V
C 8 NCB21HK-103X C CAPACITOR
C 9 NCB21HK-102X C CAPACITOR
C 21 NCB21EK-473X C CAPACITOR
C 23 NCS21HJ-3R0X C CAPACITOR
C 30 QEK61CM-476Z-JB E.CAPA I.M 47MF 20% 16V
C 31 NCS21HJ-2R0X C CAPACITOR
C 32 NCB21HK-102X C CAPACITOR
C 33 QEK61AM-107Z-JB E.CAPA I.M 100MF 20% 10V
C 34 NCS21HJ-150X C CAPACITOR
C 35 NCB21HK-102X C CAPACITOR
C 36 QEK61CM-106Z-JB E.CAPA I.M 10MF 20% 16V
C 37 NCB21EK-473X C CAPACITOR
C 39 NCB21EK-473X C CAPACITOR
C 40 NCB21HK-103X C CAPACITOR
C 41 QEK61HM-104Z-JB E.CAPA I.M .10MF 20% 50V
C 42 QEK61HM-474Z-JB E.CAPA I.M .47MF 20% 50V
C 44 NCS21HJ-221X C CAPACITOR
C 45 QEK61HM-335Z-JB E.CAPA I.M 3.3MF 20% 50V
C 46 NCB21HK-223X C CAPACITOR
C 47 NCB21HK-103X C CAPACITOR
C 49 NCB21HK-153X C CAPACITOR
C 50 NCB21HK-153X C CAPACITOR
C 51 QEK61HM-105Z-JB E.CAPA I.M 1.0MF 20% 50V
C 52 QEK61HM-105Z-JB E.CAPA I.M 1.0MF 20% 50V
C 55 NCS21HJ-120X C CAPACITOR
C 60 QEK61AM-107Z-JB E.CAPA I.M 100MF 20% 10V
C 61 NCS21HJ-120X C CAPACITOR
C 62 NCS21HJ-120X C CAPACITOR
C 63 NCB21EK-473X C CAPACITOR
C 65 NCB21HK-102X C CAPACITOR
C 66 NCS21HJ-151X C CAPACITOR
C 67 NCS21HJ-151X C CAPACITOR
C 68 NCS21HJ-151X C CAPACITOR
C 69 QEK61HM-225Z-JB E.CAPA I.M 2.2MF 20% 50V
C 70 NCB21HK-392X C CAPACITOR
C 71 QEK61HM-335Z-JB E.CAPA I.M 3.3MF 20% 50V
C 72 NCB21HK-102X C CAPACITOR
C 80 NCS21HJ-8R0X C CAPACITOR
C 81 NCB21HK-122X C CAPACITOR
C 82 NCB21EK-473X C CAPACITOR
C 83 NCB21HK-103X C CAPACITOR
C 84 NCB21HK-103X C CAPACITOR
C 85 NCB21HK-102X C CAPACITOR
C 86 NCB21HK-102X C CAPACITOR
C 90 NCB21HK-682X C.CAPA. C.M
C 91 NCB21EK-473X C CAPACITOR
C 92 NCS21HJ-101X C CAPACITOR
C 93 NCS21HJ-100X C CAPACITOR
C 94 NCS21HJ-120X C CAPACITOR
C 95 NCS21HJ-102X C CAPACITOR
C 96 NCS21HJ-8R0X C CAPACITOR
C 97 NCS21HJ-4R0X C CAPACITOR
C 99 NCB21CK-104X C.CAPA. C.M
CF 1 QAX0419-001Z C FILTER FM IF
CF 2 QAX0419-001Z C FILTER FM IF
CF 3 QAX0418-001Z C FILTER
CF 4 QAX0409-001 CERA LOCK
CN 1 QGF1205F1-10 CONNECTOR
CN701 QGF1205F1-10 CONNECTOR TO TUNER PWB
CN711 QGB1214K1-20S CONNECTOR TO AMP PWB CONT
CN712 QGB1214K1-06S CONNECTOR TO AMP PWB SIG.
CN731 QGF1205C1-09 CONNECTOR TO MECHA PWB
CN766 QGF1205F1-11 CONNECTOR TO CD PWB
CN781 QGB2016K1-03 CONNECTOR TO FRONT SW PWB
CN782 QGF1205C1-05 CONNECTOR TO TOP SW PWB
CN801 QGB2016J1-03 CONNECTOR
CN802 QGF1205F1-05 CONNECTOR
C7001 NCS21HJ-180X C CAPACITOR CLOCK
C7002 NCS21HJ-180X C CAPACITOR CLOCK
C7003 NCB21HK-103X C CAPACITOR
C7004 NCS21HJ-360X C CAPACITOR MAIN CLOCK SHIF
C7005 NCS21HJ-390X C CAPACITOR MAIN CLOCK SHIF
C7006 NCS21HJ-200X C CAPACITOR MAIN CLOCK
C7007 NCS21HJ-220X C CAPACITOR MAIN CLOCK
C7008 NCB21HK-102X C CAPACITOR
C7009 NCB21HK-102X C CAPACITOR
C7011 QER41AM-107 E CAPACITOR 100MF 20% 10V
C7012 NCB21HK-103X C CAPACITOR
C7013 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C7014 QER41CM-106 E CAPACITOR 10MF 20% 16V
C7021 QER41CM-476 E CAPACITOR 47MF 20% 16V
C7022 NCB21HK-102X C CAPACITOR
C7031 QETB0JM-228 E CAPACITOR BACKUP CAPACITO
C7051 QER61HM-684Z E.CAPACITOR .68MF 20% 50V
C7052 QER61HM-225Z E CAPACITOR 2.2MF 20% 50V
C7081 NCB21EK-104X C CAPACITOR
C7601 NCS21HJ-151X C CAPACITOR
C7602 NCS21HJ-151X C CAPACITOR
C7619 NCS21HJ-271X C CAPACITOR
C7620 NCS21HJ-271X C CAPACITOR
C7621 NCS21HJ-271X C CAPACITOR
C7622 NCS21HJ-271X C CAPACITOR
C7633 NCB21HK-102X C CAPACITOR
C7641 NCS21HJ-151X C CAPACITOR
C7644 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C7646 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C7701 NCS21HJ-151X C CAPACITOR
C7702 NCS21HJ-151X C CAPACITOR
C7705 NCS21HJ-331X C CAPACITOR
C7734 NCB21HK-102X C CAPACITOR
C7744 QER61HM-225Z E CAPACITOR 2.2MF 20% 50V
C7745 QER61HM-335Z E CAPACITOR 3.3MF 20% 50V
C7746 QER61HM-225Z E CAPACITOR 2.2MF 20% 50V
C7801 NCB21HK-103X C CAPACITOR MICOM NOISE
C7802 NCB21HK-103X C CAPACITOR MICOM NOISE
C7803 NCB21HK-103X C CAPACITOR
C7804 NCB21HK-103X C CAPACITOR
C7805 NCB21HK-103X C CAPACITOR
C7806 NCB21HK-103X C CAPACITOR
C7807 NCB21HK-103X C CAPACITOR
C7808 NCB21HK-103X C CAPACITOR
C7809 NCB21HK-102X C CAPACITOR
C7810 NCB21HK-103X C CAPACITOR
C8011 QDYB1CM-103Y C.CAPACITOR
C8012 QDYB1CM-103Y C.CAPACITOR
D 1 1SS254-T2 SI DIODE
D 2 1SS254-T2 SI DIODE
D 3 1SS254-T2 SI DIODE
D 4 1SS254-T2 SI DIODE
D 5 1SS254-T2 SI DIODE
D 6 1SS254-T2 SI DIODE
D 20 KV1555N-T VARI CAPACITOR
(Tuner board)
Item
Parts number Parts name Area
Remarks
A
