JVC UX-T77 - Page 52

UX-T77
3-9
Fig.5
Fig.1
Fig.2
EM-30L
EM-30L
Fig.5
Fig.1
Fig.2
EM-30L
Fig.3
Fig.3
Fig.4
EM-30L
Fig.4
LEN-320M
Grease point
2/3
*
*
*
Note: It is a putting up of the control
cam to UD-24H(Hanarl) and
LEN-320M(Grease)dipping on the
Control cam
