The Pro-LC controller can be installed
either indoors or outdoors and must be done
in compliance with local electrical codes.
For the best viewing and ease of programming
we recommend installation at eye level.
The mounting location should have access
to 115VAC or 220VAC electrical power and allow
enough bottom clearance for the installation of
conduit or a “junction” box if required.
Installation should be done at least 15 feet
away from a pump start relay or any high
draw motors, such as air conditioners and
refrigerators.
For ease of installation the enclosure door
and main panel can be removed. 12 inches
of horizontal clearance to the left is necessary
to fully open the hinged door.
1. Open the enclosure door and swing it to the
left until fully open.
2. Using both hands grasp both the top and
bottom portions of the door at the hinge
location.
3. Gently pull either the top or bottom portion
of the door forward until the door releases.
INSTALLATION DOOR REMOVAL
