Kaba C-lever compact Installation Instructions

Installation instructions Product description
Kaba c-lever compact k2evo703en-2011-05 10
3.4 Technical specifications
Interface
Data transfer RFID
Dimensions
Fitting HxWxD 108.5 x 60 x x25.8 mm
Pin size (standard) at least 45 mm
(depending on the door and lock)
Body
Handle Stainless steel
Power supply
Battery 2 x 1.5 V, type AAA Lithium
Service life: > 90,000 cycles or 3 years
Operating environments
Protection class IP54
Temperature
-25° ... +70° C
1)
Humidity 0 ... 95% rH, non-condensing
Climate Not suitable for heavily corrosive atmospheres
(chlorine, ammonia)
Rooms Not to be used in environments where there is a risk
of explosion
Standards
Fire protection According to EN1634-1
EN179 According to test certificate
Key:
1)
The temperature range depends on the battery manufacturer's specifications

Kaba C-lever compact Specifications

General

Brand	Kaba
Model	C-lever compact
Category	Door locks
Language	English
