Kaba C-lever compact Installation Instructions

Installation instructions Product description
Kaba c-lever compact k2evo703en-2011-05 11
3.5 c-lever compact assembly
Exploded diagram
3.6 Dimensions
Scale drawing
21
3
4
56
7
8101112
13
9
14
15
Position Description
1 Mechatronic unit
2Housing
3Metal ring
4 Plastic guide ring
5 External handle
6Direction pin
7 Batteries, type AAA Lithium (2 pieces)
8Spindle
9 Fastening screw
10 Internal rosette "round" (optional)
11 Fixing screw for internal rosette (2 pieces)
12 Internal rosette cover (optional)
13 Inside handle (optional)
14 Fixing screw for handle (optional)
15 Centring sleeve (2 pieces 7-8 mm, 2 pieces 7-9 mm)
60
108.5
114.7
65
25.8
Ø6.5
5
38
