8 • OPERATING THE ELECTRONIC OVERRIDE
PK2915-T 07_2014 E-760/770/790 SERIES RETROFIT INSTALLATION GUIDE
Page 11
Steps to activate the E-760/770/790 electronic override:
1. Insert the communication cable into the lock. Wait 2 seconds, then
connect the cable to serial port A of the FDU.
2. Press any key to activate the FDU, then swipe a PA or higher keycard through the
FDU. If the green LED on the lock flashes once, disconnect the cable from Serial
Port A, wait 2 seconds, and reconnect the cable.
Main Menu:
1 = Keycard
2 = Reset
?
3. Enter 4 to select the Programming Menu, then press < >.
Program
1 = A lock
2 = Another FDU
?
4. Wait 2 seconds. Enter 1 to select the Lock option, and press < >.
Enter Function
1 = Program Addresses
2 = Reset Addresses
?
5. Enter 6 to select the Override/Reset Time option, then press < >.
Ready to Override
or Reset Time
Strike a key,
or C to quit.
6.
Wait 2 seconds, then press any key on the FDU to activate the electronic
override.
Trying to establish link with lock
press any key to quit
7. The green LED on the lock should light. The following message should appear
on the FDU screen immediately or within 2 seconds.
Communication Successful
Press any key to continue.
8. Open the door. You have only 4 seconds after this message appears
to open the door.
9. Remove the communication cable from the lock.
Some messages on the screen may differ depend-
ing on the FDU version, but the menu choices are
the same.
