Kaba Simplex 7104 Series User Manual

4
CHECKLIST
Use this checklist to make sure that
everything has been included. 
 A – Front lock
 B – Trim Plate
 C – 2
3
⁄4" Backset Latch (7004)
– Adjustable Latch (7104)
 D – Inside Thumbturn Assembly
 E – Inside Combination Change Assembly
 F – Strike Plate
Screw Pack:
 G – 4 thru-bolts (3")
 H – 4 combination wood/metal screws
 I – 4 thru-bolts (2
3
⁄8")
 Template (in center of booklet)
DETERMINE THE HAND OF YOUR DOOR
Many of the installation instructions refer to
the handing of your door. The hand of the
door is determined with the door in the
closed position, from the exterior or
pushbutton side of the door.
A) Right Hand Door. Door opens inward
(push). Hinged on the right side.
B) Left Hand Door. Door opens inward
(push). Hinged on the left side.
C) Right Hand Reverse Door. Door opens
outward (pull). Hinged on the right side.
D) Left Hand Reverse Door. Door opens
outward (pull). Hinged on the left side.
LH - Left Hand
RH - Right Hand
LHR - Left Hand Reverse
RHR - Right Hand Reverse
A
B
C
D
A
G 3"
E
F
I 2
3
⁄8"
H
D
C
B


Kaba Simplex 7104 Series Specifications
