Kaba SIMPLEX 7108 Series User Manual

1
3
/4"
(44 mm)
1
3
/8"
(35 mm)
2"
(51 mm)
1
1
/2 "
(38 mm)
CAUTION
Apply template and drill
from the outside but
compensate for door
bevel if any
Deadbolt cutout
1
2
1
/4"
(57 mm)
1" dia.
(25 mm)
4" deep
(10 cm)
1
5
/8
"
(41 mm)
*backset
1"
(25 mm)
2
1
/4"
(58 mm)
Bore
1" (25 mm) dia.
latch hole
*
MARK
ACCURATELY
BORE
STRAIGHT
LEFT HAND DOOR
7102 / 7108
TEMPLATE
NOTE: Lock will accomodate doors
1
3
/8" (35 mm) to 2
1
/4" (57 mm) thick.
Suitable reinforcement shall be provided
by the hollow metal door manufacturer
to prevent collapsing of door. When
door silencers are to be installed,
proper allowances must be made for
strike location.
*
Edge of door for 2
3
/4" (70 mm) Backset
* For both 2
3
/8" (60mm) and 2
3
/4" (70mm) backsets
IMPORTANT
Use this as edge of
door when boring hole
Mark center of
door thickness

Kaba SIMPLEX 7108 Series Specifications

General

Brand	Kaba
Model	SIMPLEX 7108 Series
Category	Door locks
Language	English
