Important: Please keep these instructions. The combination of this lock has
been factory preset: 2 and 4 pressed together, then 3.
WARNING: For your own safety, you must change the combination at the
time of installation.
PLEASE READ AND FOLLOW ALL DIRECTIONS CAREFULLY
Since every installation is unique, carefully check windows, frame, door, etc. to
ensure that the recommended procedures will not cause damage. KABA is not
responsible for any damage caused by installation.
Tools Required
• Flat blade screwdrivers (small and medium)
•
3
⁄4" (19 mm) to 1
3
⁄8" (35 mm) hole saw
• Center punch
• Drill
• Hammer
• Two pairs of pliers
Use this checklist to make sure that everything has been included. J
J
Front lock assembly
J Mounting bracket with tailpiece assembly
J Control key
J Four mounting screws (sheet metal No. 7 pan head screws)
J Allen wrench
5
⁄64" (2 mm) x 1
31
⁄32" (50 mm)
J Registration card
Table of Contents
1. Preparing for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2. Adjusting the Drive Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3. Shortening the Connecting Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
4. Installing the Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
5. Operating the Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
6. Changing the Combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
7. Instructions for Resetting an Unknown Combination . . . . . . . . . . . . . . . . . . . . . . . . .9
Note: There is no 2015 template, as it is not required for install.
