KACO Gerätetechnik GmbH 2 Installation Instructions Powador 01xi
1. About this document
The following information will guide you through the
entire documentation. Further documents will be valid
in conjunction with these operating and installation
instructions.
We shall not be liable for any damage caused by non-
adherence to the instructions given in this manual.
Pertaining documents
During the inverter installation please observe all
assembly and installation instructions for components
and other parts of the system. These instructions are
shipped together with the respective installation
components or supplementary equipment.
1.1 Attachment and Maintenance of documents
Please keep these operating and installation
instructions in a safe place to ensure that they are
available if needed.
1.2 Symbols used in this document
Please observe the safety information provided in this
manualw hen operating your inverter!
1.3 CE Certification/Labeling
CE labeling is used to document that the Powador
inverter indicated on the type label meets the
fundamental requirements according to the following
directives:
- Directive concerning Electromagnetic Compatibility
with Class B (Council Directive 89/336/EWG)
-Low Voltage Directive (Council Directive 73/23/EWG
1.4 Type label
The type label indicating the exact device description is
located on the support panel at the underside of the
enclosure.
2. Safety information and instruct-
ions
Standards and Regulations
- VDEW conformity according to the regulations of the
Association of German Utility companies
- “Independent power generating plants on low-voltage
grids”, Directive concerning the connection and
parallel operation of independent power generating
plants on the low-voltage grid, 4
th
Edition 2001
- IEC 60364-7-712 Electrical installations of buildings -
Part 7-712
- DIN EN 60891 Process of converting measured
current-voltage characteristic curves of photovoltaic
components
- DIN EN 60904 Photovoltaic Installations – Part 1 to 8
- EMC Test Methods according to EN50081-1:1992,
EN50082-1:1997
- Emitted interference: EN 55014-1: 1993
- Interference immunity: EN 55014-2: 1997
- Harmonic (upper) waves: EN61000-3-2: 1995
- Voltage fluctuations + Flicker: EN61000-3-3: 1995
- Semiconductor inverters: EN 60146-1-1: 1994,
EN60146-1-3: 1994
Technical rules
The assembly must be in compliance with the local
regulations and technical rules, in particular with regard
to:
- Electrical connections
- VDE 0100 Setting-up of power installations with rated
voltages of up to 1000 volts
- VDE 0105 Part 100 Operation of electrical
plants/installations
- VDE 0185 General information concerning the setup
of lightning protection installations
Danger!
Danger due to lethal voltages!
Hazardous live voltages are present inside
the device/instrument and power lines.
Therefore, the device/instrument must only
be installed and opened by a skilled
electrician.
Even when the device/instrument is
switched off, dangerous live voltages may
still be present inside the instrument.
Danger
Important!
Non-adherence to these
instructions may adversely affect
the operating convenience or
functionality of the device.
This symbol indicates that a
certain action is required.
Note!
Useful information and remarks
Danger!
Lethal Hazard by Electric Shock!
Danger
Caution!
Potential hazard for the product
and environment!
Caution
Warning!
Lethal Hazard!
Warning
