AIRTOWER 3C AIRTOWER 4C AIRTOWER 5C AIRTOWER
7.5C
Cooling air tempera‐
ture [°F]
40 – 115 40 – 115 40 – 115 40 – 115
Intake air temperature
[°F]
40 – 115 40 – 115 40 – 115 40 – 115
* Higher altitudes are permissible only after consultation with the manufacturer.
Tab. 7 Ambient conditions
Fig. 1 Maximum relative humidity of intake air
T Intake air temperature [°F]
H Maximum relative humidity of intake air [%]
2.6 Ventilation
The values given are minimum guide values.
AIRTOWER 3C AIRTOWER 4C AIRTOWER 5C AIRTOWER
7.5C
Inlet aperture Z see fig‐
ure 11 [sq. ft.]
2.2 2.2 2.2 2.2
Extractor for forced venti‐
lation:
Flow rate [cfm] at 100 Pa.
883 1001 1236 1530
Tab. 8 Ventilation
2.7 Pressure
Maximum working pressure: see nameplate
2 Technical Data
2.6 Ventilation
6
Operator Manual Screw Compressor
AIRTOWER 3C–7.5C Tri-Voltage 9_6917 34 USE
