Katherm HK
Assembly, installation and operating instructions
76
Parameter Function Standard Min. Max. Unit Katherm HK
9
Katherm HK
E
10
P069 Network address 1 0 207 - 1 1
P070 Dependence of the hydronic algorithms (on slaves) 0 0 7 - 0 0
P071 Serial address of slave 1 0 0 207 - 0 0
P072 Serial address of slave 2 0 0 207 - 0 0
P073 Serial address of slave 3 0 0 207 - 0 0
P074 Serial address of slave 4 0 0 207 - 0 0
P075 Serial address of slave 5 0 0 207 - 0 0
P076 Serial address of slave 6 0 0 207 - 0 0
P077 Serial address of slave 7 0 0 207 - 0 0
P078 Serial address of slave 8 0 0 207 - 0 0
P079 Serial address of slave 9 0 0 207 - 0 0
P080 Serial address of slave 10 0 0 207 - 0 0
P081 Dependence of the hydronic algorithms, slave 1 0 0 7 - 0 10
P082 Dependence of the hydronic algorithms, slave 2 0 0 7 - 0 18
P083 Dependence of the hydronic algorithms, slave 3 0 0 7 - 0 0
P084 Dependence of the hydronic algorithms, slave 4 0 0 7 - 0 0
P085 Dependence of the hydronic algorithms, slave 5 0 0 7 - 0 0
P086 Dependence of the hydronic algorithms, slave 6 0 0 7 - 0 0
P087 Dependence of the hydronic algorithms, slave 7 0 0 7 - 0 0
P088 Dependence of the hydronic algorithms, slave 8 0 0 7 - 0 0
P089 Dependence of the hydronic algorithms, slave 9 0 0 7 - 0 0
P090 Dependence of the hydronic algorithms, slave 10 0 0 7 - 0 0
P091 Load default values 0 0 255 - 0 0
P092 Password management 0 0 255 - 0 0
P093 Type of pre-comfort (room occupancy) 0 0 3 - 0 0
P094 Pre-comfort timer 60 1 255 min 60 60
P095 Disable DIP switch settings 0 0 1 - 0 0
P096 Digital outputs continuously activated 0 0 1 - 0 0
P097 Read off DIP switch - 0 63 - - -
P098 Activation 0..10 V: valve switch on limit 30 0 100 V/10 40 40
P099 Activation 0..10 V: min. switch on limit for fan speed 40 0 100 V/10 40 40
P100
Activation 0..10 V: max. switch on limit for fan
speed
90 0 100 V/10 90 90
P101
Valve activation by pulse width modulation of P-
band in heating mode
15 0 100 K/10 15 15
P102
Valve activation by pulse width modulation of P-
band in cooling mode
15 0 100 K/10 15 15
P103
Valve activation by pulse width modulation of reset
time of PI controller
0 0 20 min 0 0
P104 Minimum ON time with PWM valve activation 3 0 20 min 3 3
P105 Compensation: max. negative delta setpoint 50 0 150 K/10 50 50
P106 Compensation: max. positive delta setpoint 50 0 150 K/10 50 50
P107 Duration of valve open to check water temperature 5 0 255 min 5 5
P108 Duration of valve closed 240 35 255 min 240 240
P109 Dead zone PI control for 3-way valve 10 0 100 K/10 10 10
P110 Hysteresis to switch between heating / fan mode 0 0 20 °C 0 0
P111 Threshold to switch between heating / fan mode 0 0 50 °C 0 0
