4 Technical data
Unit Venkon EC
Unit Venkon EC
Model 61 63 66 67
1
at LPHW 75 / 65°C, t
L1
= 20°C
2
at CHW 7/12°C, t
L1
=27°C, rel. humidity 50%
3
at LPHW 120 / 100°F, t
L1
=68°F
4
at CPW 45/55 °F, t
L1
= 75°F rel. humidity 50%
Model 61 63 66 67
Length of basic unit [mm] 625 925 1375 1725
Casing length [mm] 900 1200 1650 2000
Weight of basic unit [kg] 19 24.5 36.5 46.5
Air volume [l/s] 50 – 215 65 – 275 115 – 480 130 – 545
Internal volume of 2-pipe
system [l]
1.3 2.0 3.1 3.9
Internal volume of 4-pipe
system [l] heating
0.5 0.6 0.9 1.1
Internal volume of 4-pipe
system [l] cooling
1.0 1.6 2.4 2.9
MCA [A] 1.25 1.50 2.75 3.25
MOP [A] 15 15 15 15
Heat output [kW]
1
2.8 – 11.2 3.4 – 14.7 5.9 – 24.9 7.2 – 29.9
Cooling output [kW]
2
1.2 – 4.0 1.4 – 5.7 2.5 – 9.6 3.1 – 12.2
Sound power level [dB(A)] 35 – 68 29 – 60 36 – 69 32 – 63
Length of basic unit [inch] 24.6 36.4 54.1 69.9
Casing length [inch] 35.4 47.2 65 78.7
Weight of basic unit
[pound]
41.9 54 80.5 102.5
Air volume [cfm] 110-455 135-580 240-1020 275-1150
Internal volume of 2-pipe
system [US gal.]
0.29 0.30 0.31 0.32
Internal volume of 4-pipe
system [l] heating [US gal.]
0.29 0.30 0.31 0.32
Internal volume of 4-pipe
system [l] cooling [US gal.]
0.29 0.30 0.31 0.32
MCA [A] 1.25 1.50 2.75 3.25
MOP [A] 15 15 15 15
Heat output [MBH]
3
4.6-14.4 5.8-20.8 9.9-34.3 12.1-42.9
Cooling output [MBH]
4
3.1-8.3 3.6-12.7 6.4-21.1 7.7-27.5
Sound power level [dB(A)] 35-68 29-60 36-69 32-63
