Venkon
Assembly, installation and operating instructions
41
7.2 Electromechanical control, Venkon EC
7.2.1 Connection (U02M), Venkon EC
Fig.29: junction box
The junction box for electromechanical control (EC) as well as
the junction box for the condensation monitor can be electric-
ally installed separately from the side panel of the basic unit.
Simply remove the covering with screws to open the junction
box.
