Kampmann Venkon - Minimum Clearances

Venkon
Assembly, installation and operating instructions
18
6.3 Minimum clearances
Air outlet area*
Air outlet area*
Example of basic unit, wall-hanging (without casing)
Example of unit, wall-hanging with casing
Example of basic unit, ceiling (without casing)
Example of unit, ceiling-mounted with casing
6.5
3.9
3.9
6.5
1 1
1
1
6.5
3.9
6.5
3.9
3.9
3.9
*The air outlet area needs to be
completely barrier-free to guarantee
the free circulation of air! There
needs to be a 50 mm freely
accessible clearance above the casing
to be able to remove the casing.
Fig.4: Minimum clearances
