Kampmann Venkon - Electrical Wiring; Electrical Rating Values

Venkon
Assembly, installation and operating instructions
40
7 Electrical wiring
IMPORTANT NOTE!
Condensation formation in the cooling unit!
In the event of on-site valve control, the cooling valve must be closed when the fans are switched off.
7.1 Maximum electrical rating values
Venkon EC, electromechanical model (U02M)
Tab.10: Maximum electrical rating values for Venkon EC
Model Number of fans Nominal voltage Mains fre-
quency
Nominal power Nominal
current
Protection
rating
Protection
class
61 1x Single 115 V~ 60 Hz 65 W 1.0 A IP20 I
63 1x Tandem 115 V~ 60 Hz 100 W 1.5 A IP20 I
66
1x Single, 1x Tan-
dem
115 V~ 60 Hz 136 W 2.1 A IP20 I
67 2x Tandem 115 V~ 60 Hz 170 W 2.4 A IP20 I
