1. ANALYSER LAYOUT AND FEATURES
1.1 Instrument Features and Keypad
ON/OFF
UP
Scrolls up through options ie Fuel
MENU
Allows access to all menu functions
DOWN
Scrolls down through options
PUMP
Turns pump on and off
STORE
Enters data storage menu
ENTER
Accepts a command ie enters a
menu option
PRINT
Prints current data
RS232 (8 pin din)
Charger socket
Store
Print
Pump
Enter
Menu
On/Off
Up
Down
Keypad
Flue Temperature
Connector (underside)
Inlet Port (side)
Pressure Inlet
Infra-red emitter
