CAN RANGER OPERATION
11
CAN ACTUATOR ID
ASSIGNMENT
Kar-Tech CAN Actuators are
pre-assigned at the factory
and labeled for each function.
The following procedure is
only if reassignment is
required in case of actuator
replacement or if two identical
actuators are detected.
Note: If the receiver ever
detects two or more
actuators with the same
ID, it will stop operation
and indicate errors. The
receiver tests for this
every time it is powered up
and continually as it runs.
Since all actuators are
identical, they need to be
assigned identification
numbers by the receiver in
order to distinguish which
actuator does what function.
Using the buttons on the CAN
Ranger Receiver, navigate
through the LCD screens to
CALIBRATION. Press <SET>.
Use the arrow buttons to
enter the password 1262.
Enter the password by
pressing <SET>. The first
screen in the Menu is
ASSIGN ACTUATORS
PUSH SET
After selecting this by pushing
SET, the receiver’s LCD will
walk the operator through the
procedure. The basic idea is
that all actuators need to be
disconnected from the
system. This means both
disconnecting the wire
cable and disconnecting
the mechanical linkage
from the shaft of the
actuators. Next, one by one
