CAN RANGER OPERATION
19
RPM CALIBRATION
PLEASE NOTE: THE KAR-
TECH CAN RANGER CAN BE
CONFIGURED TO PROVIDE
MANY DIFFERENT TYPES
OF RPM SIGNALS. MAKE
SURE THE SYSTEM IS
CONFIGURED FOR THE
CORRECT TYPE OF OUTPUT
FOR YOUR ENGINE.
The CAN Ranger is calibrated
at the factory for Cummins
engine. Refer to appendix B
for factory setting
parameters.
Using the buttons on the CAN
Ranger Receiver, navigate
through the LCD screens to
CALIBRATION. Push <SET>.
Use the arrow buttons to
enter the password 1262.
To enter the password, use
the → button to change which
digit you are changing. Use ↑
to increase the selected digit
or ↓ to decrease it. Use ← to
back out of this screen and
return to the Calibration
Menu. Once you have
changed all 4 digits, push
<SET>. If you entered the
correct password you get the
help screen:
USE ←→ TO PICK
Then push the right button
(FWD arrow) to get to the
RPM SETUP screen:
RPM SETUP
← PUSH SET →
Push <SET>.
Scroll until you get the type of
RPM you want. The options
are:
Caterpillar
Cummins
International
Mercedes
