CAN RANGER OPERATION
2
DESCRIPTION
The CAN RANGER is a state of
the art microprocessor based
Radio Frequency (RF) control
system. It will provide the
operator the ability to
remotely operate equipment.
The operator is required to
follow all OSHA www.osha.gov
safety standards when
operating the equipment.
This system is designed with
Frequency Hopping Spread
Spectrum (FHSS) and Phase
Lock Loop (PLL) technology
for the optimum performance
in radio remote products.
The remote control system
consists of several modules:
the radio transmitter, receiver
module, actuators, wiring
harnesses, charger and
associated optional equipment
such as Palm™ interface tools.
The transmitter is equipped
with joysticks and toggle
switches for various functions.
It includes a port for charging
the internal battery.
The system’s radio receiver is
designed with 8 ON/OFF
outputs to drive the Horn,
Engine Start, Engine Stop,
RPM+, RPM-, Basket Tilt up,
Basket Tilt Down, Auxiliary
and an Analog RPM. There
are inputs for various options
like ATB/ Swing CW STOP and
OVL/Swing CCW STOP. All
outputs are protected for over
load and short circuit.
The receiver also includes a
CAN bus for communicating
with the CAN Actuators.
