KAR-TECH CAN RANGER - Actuator Pictorial View

CAN RANGER OPERATION
47
RECEIVER PICTORIAL
8.91
2.63
8.74
8.24
4.56
REAR MOUNTING HOLES
1 2 3
6 5 4
ENG. STOP -7
AUXILIARY -8
TILT UP IN -9
TILT DN IN -10
ANALOG RPM -11
ANALOG OUT -12
6- ENG. START
5- TILT DOWN
4-TILT UP
3- HORN
2- RPM -
1- RPM+
3- GROUND
2- POWER
1- POWER
GROUND -4
CAN LOW -5
CAN HIGH -6
PAGE DN
PAGE UP
BACK
FWD
SET 
USER ASSIST DISPLAY
DIAGNOSTICS PORT
GROUND -5
R232 RX -2
RS-232 TX -1
