English 15
Cleaning the roller brush
1. Remove the brush cover if necessary:
Use a coin to turn the rotary lock by 90°
and remove the brush cover.
2. Cut off hair and threads wound onto the
roller brush using scissors and remove
them.
Changing the filter bag
1. Unlock and remove the filter cover.
2. Turn the filter bag lock to the right to un-
lock. Close the filter bag, remove and
dispose of it.
3. Insert a new filter bag and turn the filter
bag lock to the left to lock.
4. Fit and lock the filter cover.
Replacing the exhaust filter
1. Unlock and remove the filter cover.
2. Push the filter casing locking mecha-
nism upwards and remove the filter cas-
ing.
3. Remove the exhaust filter from the filter
casing.
4. Insert a new exhaust filter in the filter
casing.
5. Insert the filter casing and latch it into
place.
6. Fit and lock the filter cover.
Replacing the motor protection filter
1. Unlock and remove the filter cover.
2. Press the motor protection filter lock up-
wards. Remove the old motor protection
filter and dispose of it.
3. Fit and lock the new motor protection fil-
ter.
4. Fit and lock the filter cover.
Replacing the roller brush
Please make sure that the bracket is al-
ways completely opened during installa-
tion.
1. Fold the bracket on the side section fully
upwards and remove the side section.
2. Pull out the old roller brush and dispose
of it.
3. Insert a new roller brush in the side sec-
tion.
4. Push the side section together with the
roller brush into the device.
5. Fold the bracket fully downwards to lock
the side section.
Troubleshooting guide
Remove the blockage
Suction pipe/suction hose

Table of Contents

Other manuals for Kärcher CV 30/1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kärcher CV 30/1 and is the answer not in the manual?

Kärcher CV 30/1 Specifications

General IconGeneral
Airflow43 l/s
Product typeUpright vacuum
Dust capacity5.5 L
Product colorBlack, Grey
Dust container typeDust bag
Standard nominal width- mm
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Maximum input power850 W
Noise level66 dB
Dirt separating methodFiltering
Working width (standard brush)300 mm
Weight and Dimensions IconWeight and Dimensions
Depth310 mm
Width320 mm
Height1220 mm
Weight8400 g
