Kärcher HDC Series User Manual

Deutsch 5.962-786.0 Rev. 05 (06/13) 79
Example 3: Installation with (foam) injector, without quick
coupling
Example 4: Installation with (foam) injector, with quick cou-
pling
No. Name Order No.
1 High pressure ball valve 6.412-066.0
2 Double adapter 5.402-001.0
3 Injector /
foam injector
3.637-001.0
3.637-054.0
4 HP hose e.g. 6.391-342.0
7 Wall mount for 2 detergent tanks 2.641-703.0
No. Name Order No.
1 High pressure ball valve 6.412-066.0
2 Double adapter 5.402-001.0
