Karel MS48 Installation & Maintenance Guide
Edition 3.2
18
•
D
ATA FORMAT OF
CM48:
A call record consists of two lines, each followed by Carriage return (0Dh) and
Line Feed (0Ah) characters.
Structure of the first line:
Starting Character Position Field Width Information
1 1 #; indicates start of record
2 4 4 digit counter value
6 1 Space
7 4 or 2 Call type
11 1 Space
12 1 Common Pool information
- Call type:
LDIS Long Distance
INTL International
IC Incoming
Call type field and the preceeding space are not sent to PC for local calls.
- Common pool information field contains the character C to indicate calls
made from the common pool. If the call was not made from the common
pool then this field and the preceding space are not sent to PC.
Structure of the second line:
Starting Character
Position
Field
Width
Information
1 8 Date in the format dd/mm/yy
9 1 Space
10 8 Starting time of the call in the format hh:mm:ss
18 1 Space
19 8 Ending time of the call in the format hh:mm:ss
27 1 Space
28 5 Call duration in the format mm:ss
33 1 Space
34 4 Starting extension number, OPE for the
operator and Dtt for the incoming calls coming
from a DISA line where tt is the line number.
38 1 Space
39 4 Ending extension number, OPE for the
operator.
43 1 Space
44 3 Call Info
47 1 Space
48 2 Line number
50 1 Space
