Karel MS48 Installation & Maintenance Guide
Edition 3.2
15
The outlook and BDP of DSS40 are illustrated in the following figures.
Figure A-13
Figure A-14
The dimensions of the DSS40 are 16 cm x 22 cm x 6.5 cm and the weight is 0.7 kg.
II.2. MINI PRINTER - KY16
MS48 system offers
Call Record Listing (CRL)
facilities, by keeping the records of
the external calls and storing them in its non-volatile memory against any power
failure. You may obtain these records by way of some external devices.
One of these external devices is KY16 Mini Printer, which gives 16-column printout
using an Epson type print head.
The following figure illustrates the outlook of KY16 Mini Printer.
