Karel MS48 - Page 3


ii
SECTION
PAGE
INSTALLATION
I. PRELIMINARY NOTICE 33
I.1. DELIVERY CHECK 33
I.2. INSPECTION 33
I.3. ENVIRONMENTAL REQUIREMENTS 33
II. SYSTEM INSTALLATION 35
II.1. GROUNDING 36
II.2. SPS48 POWER SUPPLY MODULE 37
II.3. MB48 MOTHERBOARD & EXP48 EXPANSION MODULES 38
III. ACCESSORY INSTALLATION 41
III.1. CONSOLES, FEATURE PHONES, DIRECT STATION SELECT
MODULES
41
III.2. MINI PRINTER 45
III.3. PC INTERFACE 49
III.4. SERIAL PRINTER INTERFACE 50
III.5. DOORPHONE 51
III.6. EXTERNAL ANNOUNCEMENT SYSTEM 53
III.7. AUTO ATTENDANT & VOICE MAIL 54
III.8. ISDN ADAPTOR 55
III.9. LOCAL PAGER 58
III.10. STANDARD TELEPHONE SETS, EXTERNAL LINES 61
III.11 FILTER & PROTECTION UNIT 62
III.12. EXTERNAL MUSIC SOURCE 63
III.13. EXTERNAL RELAY 64
MAINTENANCE
I. MAINTAINING THE SYSTEM 67
