Optional Rectangular Collimator
NOTE: The optional Rectangular Collimator Cone Adapter dimensions are contained entirely
within the 6 cm circular exit field diameter. This collimator can rotate freely, 360 degrees.
Optional
Rectangular Collimator
Exit Field Size
3 cm x 4 cm
X-ray
Beam
X-ray Source Focal Spot
X-ray Source Focal Spot
Rectangular Axis at 90o
to Target Receptor
