5
安裝要求
INSTALLATION REQUIREMENTS
請勿安裝在傾斜的天花板上。
防止水倒流。
Do not install onto slanting ceiling.
Prevent the water condensed in the
duct pipe flow back into the body.
Pleasemakesuretheproductis installed
horizontallyandthedeviationangle
withintherangeasbelowfigure.
Do not install the product in the places
where the organic solvent is used.
Do not install the product in steam
sauna bathroom.
Do not install the product where it is
exposed to oil mist.
Do not install the product in the
places where the sprayer is used.
請勿安裝在桑拿蒸氣浴室中。
請勿安裝在使用噴霧器的場所。
請勿安裝在油煙過多的場所。
請勿安裝在使用有機溶劑的場所。
Please set ventilation holes.
Ambient temperature
above 40 °C.
Within
50 cm
50 cm
以內
Do not install the product in places
with high temperature.
請勿安裝在高溫的環境下。
請設置通風口。
周圍溫 度 40 °C以 上
Do not install this product in a public bath room.
Do not install this product in a wardrobe.
請勿把本產品安裝在公共浴室。
請勿把本產品安裝在衣櫃內。
蒸汽
Steam
請確保整機水平安裝偏差角度在±2°之間。
When the ceiling is unable to dismantle,
please set a square inspection hole of at
least 45 cm (The inspection hole should
not be directly under the duct pipe).
吊裝且天花板無法拆下時，請設置一個邊長
45 cm以 上的方形點檢口(點檢口不能在管道
正下方)。
方便安裝、維修
Convenience for
installation and
maintenance.
The pipe for hanging clothes should be installed at the position of 250 mm
apart from the product, please see P.21 for details.
掛衣用管的安裝應距離產品250 mm，詳細請參考第21頁。
Wave pipe
Adapter
Do not form the duct as shown below:
安裝管道應該避免以下情況：
管道
出風口接頭
