KEB ACOMBIVERT F5 X3A Reference Manual

Table 2.2.4.2 - 480V Units
SCCR UL 248 Semiconductor
Unit Size /
Housing
[kA] rms Class J Rating [A] Fuse Number* / Rating [A]
13 / E 10 25
50 140 06 40 / 40
14 / E 10 30
50 140 06 50 / 50
14 / G 10 30
50 140 06 80 / 80
15 / E 10 40
50 140 06 80 / 80
15 / G, H 10, 18 40
50 140 06 40 / 40
16 / G, H 10, 18 50
50 140 06 63 / 63
17 / G, H 10, 18 60
50 140 06 80 / 80
18 / H 18 70
50 140 06 80 / 80
19 / H 18 90
50 140 06 100 / 100
19 / R 100 90 - -
20 / H 18 100 - -
20 / R 100 100 - -
21 / R 100 150 - -
22 / R 100 175 - -
23 / R,U 100 200 - -
24 / R,U 100 225 - -
25 / U 100 275 - -
26 / U 100 300 - -
27 / U 100 350 - -
28 / W 100 400 - -
* Semiconductor fuses are manufactured by Siba Fuse Inc. When using this type of fuse,
this is the model number of the fuse that must be used.
