The encoder feedback interface is a modular board installed on the control
card of the drive, depending on the encoder type. If the encoder interface
is pre-installed by the factory, it will be denoted in the 10th digit of the drive
material number (e.g., 20F5A1H-RLBB). The encoder feedback interface
board will have two ports, X3A and X3B. Various options are available for
each port, with each combination having a unique indicator in the part num-
ber digit.
The primary channel X3A will be the input connection from the motor en-
coder. The following encoder interface types are available:
• Incremental, TTL (screw terminal strip or subD)
• Incremental, HTL (screw terminal strip or subD)
• EnDat
• Sin/Cos
• SSi
• Hiperface
• UVW
• Resolver
• BiSS / EnDat 2.2
The secondary channel X3B can be either an emulated output of the en-
coder input or a secondary input (e.g., hoistway position, governor encoder,
etc.). The following input and output types are available:
• Incremental, TTL output (screw terminal strip or subD)
• Incremental, TTL input (screw terminal strip or subD)
• SSi input
For information on interfaces without details listed in this manual,
contact KEB.
3.3 Encoder
Feedback
Interfaces
ONLY when the inverter is switched off and the voltage
supply is disconnected may the feedback connectors be
removed or connected!
Encoder Feedback Overview
51
