The Basic Setup is where the initial programming must begin. Here, the

application fundamentals are established prior to conguration.

Note: In most cases, the elevator control manufacturer will make the

adjustments in Basic Set-up, but it is good to verify the correct settings.

Before conguring the elevator drive, view the controller reference pa-

rameter list (provided by the elevator control manufacturer) to verify the

parameters required for the particular installation of the elevator drive.

The Basic Setup menu can be accessed by:

Home > Prog (F3) > Basic Setup.

All these parameters must be adjusted:

• US02 - System Units (Imperial/Metric)

• US03 - Motor Type (i.e. Induction geared or PM synch gearless)

• US04 - Control Type (i.e. Binary, Serial, Analog)

Next, the conguration must be loaded using US05. This step serves to load

the KEB drive with the correct limits and internal settings according to the

application:

• US05 - Load Conguration

(Write cong. to drive)

If loaded successfully, US05 should change from

Not congured to Conguration

OK,

indicating the drive and operator are synched.

If the US04 Control Type or US02 System Units settings are changed after

a conguration has been loaded, a new conguration must be written

to the drive. Writing the new conguration will NOT default all previous

settings.

If the US03 Motor Type must be changed after a conguration has been

loaded, a new conguration must be written to the drive, and writing the

new conguration WILL default all previous settings.

Then, enter the contract speed of the application. This will set the speed safety

limits internal to the drive:

• US06 - Contract Speed

SETUP OF THE BASIC INFO IS NOW COMPLETE!

Next, the inputs and outputs must be congured and assigned functionality

depending on the controller requirements.

5.3 Basic Setup

5.4 Inputs/Output

Conguration

Initial Startup
