21
CP-Parameter for open-loop operation
Value Function
24 act. utilization (CP06) > switching level
25 Amount actual active current > switching level
26 DC link voltage (CP07) > switching level
27 Actual value (CP01) > switching level
28 Setpoint (CP02) > switching level
30 Actual torque > switching level
31 Absolute value AN1 > switching level
32 Absolute value AN2 > switching level
34 Setpoint AN1 > switching level
35 Setpoint AN2 > switching level
37 Timer 1 > level
38 Timer 2 > level
40 Hardware current limit activated
41 modulation on
42 ANOUT3 PWM signal
43 ANOUT4 PWM signal
44 Inverter status > switching level
45 Heat sink temperature > switching level
46 Motor temperature > switching level
47 Ramp output value > switching level
48 Apparent current (CP04) > switching level
49 Forward running (not at nOP, LS, abnormal stopping or error)
50 Reverse running (not at nOP, LS, abnormal stopping or error)
51 OL2 warning
52 Current regulator limit reached
59 Inputs in AND-operation (ru22)
60 Inputs in OR-operation (ru22)
61 Inputs in NAND-operation (ru22)
62 Inputs in NOR-operation (ru22)
63 Absolute ANOUT1 > switching level
64 Absolute ANOUT2 > switching level
65 ANOUT1 > switching level
66 ANOUT2 > switching level
69 ext. PID system deviation > switching level
70 Driver voltage active
73 Absolute active power > switching level
74 Active power > switching level
80 Active current > switching level
82 Real value channel 2 > switching level
84 Actual value < minimum setpoint oP06/oP07
85 Warning ! External fault
86 Warning ! bus
89 Actual value < setpoint • switching level
90 Motor temperature correction > switching level
92 Quick stopping
99 Warning ! ow control
100 Combination of different conditions
101 Stop after DC braking and when current > switching level
(output switches at modulation = OFF and the measured average value of the
apparent value of the apparent current during DC braking before switching off the
modulation has exceeded the level of CP34)
The switching condition is off for unlisted values.
