KEB COMBIVERT R5-C User Manual

GB - 8
2.4 Technical data
Product description
1)
The typical inverter ratings are only assignment references for the components. The drive powers
are dependent on the connected motors and must be designed accordingly.
2)
The max. short time current limit is specied for 1 minute. The overload cycle is 300 seconds. This
corresponds to duty class 2 EN 60146-1-1.
3)
The current data are based on a fundamental frequency component of g=0,75. The fundamental
frequency component or the effective value of the input current is dependent on load and line supply
conditions. At uncontrolled B6 converters the phase angle cosφ1 can be set to one, so the value of
the fundamental frequency components is equal to the value of the power factor.
The units are not short-circuit proof without corresponding dimensioned fuses.The max.
loadable DC link capacity is 100000 µF. Exceeding the capacity triggers the error "charge
time out" (E.cto). Do not charge the DC link during the load cycle.
Rectiersize
19 23 25 27 28 29
Housing size
R R R U U U
Chargeable inverter power
1)
[kW]
30 75 110 160 200 250
DC nominal output current [A
DC
]
90 180 270 380 470 610
Max. short time current
2)
[A
AV
]
135 270 405 570 705 915
OL current [A
DC
]
153 306 459 646 799 1037
Input current
3)
[A
RMS
]
79,8 147,5 221 312 386 500
Mains voltage [V AC
RMS
]
305…504 +/- 0%
Phases
3
Output voltage [V DC]
430…713
Maximal permissible mains fuse [A]
100 200 350 500 710 710
I
2
t mains fuse [A
2
s]
<19.100 <128.000 <236.000 <423.000 <1.062.000 <1.062.000
Supply line cross section (min) [mm
2
]
35 95 150 2x150 2x185 2x185
Supply line cross section (max) [mm
2
]
95 150 150 2x185 2x185 2x185
DC line cross section (min) [mm
2
]
50 120 150 2x150 2x150 4x95
DC line cross section (max) [mm
2]
95 150 150 4x185 4x185 4x185
Storage temperature [°C]
-25…70
Operation temperature [°C]
-10…45
Climatic category (EN 60721-3-3)
3K3
Protective system
IP20 IP00
Power loss at nominal operating [W]
ca. 220 ca. 400 ca. 600 ca. 1050 ca.1200 ca.1600
Max. heat sink temperature [°C]
90
Internal braking option
Option
Max. braking current [A]
133 133 200 250 250 250
Min. braking resistor [Ohm]
6 6 4 3,2 3,2 3,2
Typ. braking resistor [Ohm]
15 6,7 4,3 4,3 3,2 3,2
Line cross section braking resistor [mm
2
]
35…95 16…185
Weight [kg]
28 49 54 56
