KEB COMBIVERT S6 Series User Manual

24
PRODUCT DESCRIPTION
2.4 Type code
x x S 6 x x x - x x x x
Reserved 0: Reserved
Reserved 0: Reserved
Type of control
COMPACT
1: Multi Encoder Interface, EtherCAT
1)
2: Multi Encoder Interface, VARAN
APPLICATION
1: Realtime Ethernet Module, Multi Encoder Interface
PRO
1:
Multi Encoder Interface / Ethernet-Fieldbus-Interface
4:
no Encoder / Ethernet-Fieldbus-Interface / Safe
relay
5:
Multi Encoder Interface / Ethernet-Fieldbus-Inter-
face / Safe relay
Version power unit
1: AC480V3-phasewithHFlter
2: AC480V3-phasewithoutHFlter
2)
3: AC230V1-phasewithHFlter
4: AC230V1-phasewithoutHFlter
2)
Housing 2, 4
Safety module
1: Type 1 for Strg A (STO / SBC) or STO for Strg K
3: Type 3 for Strg A (STO / SBC / SLS etc.)
5: Type 5 STO / SLS / etc. FSOE
Control type
A: APPLICATION
K: COMPACT
P: PRO
Series COMBIVERT S6
Device size 07…14
3)
Table 1: Type code
1)
EtherCAT
®
is a registered trademark and patented technology licensed by the com-
pany Beckho Automation GmbH, Germany.
2)
An external lter is required for these devices in order to comply with the limit values according to EN 61800-3.
3)
Device size 14 is only available in the version without integrated HF lter.
Thetypecodeisnotusedasordercode,butonlyforidentication!
